KDH213

Toyota HIACE · 2013 · 3,648 parts · 213 categories

3,648 items

Side Member ([12.2013 - ] LH (1312- )KDH21#,LH212,TRH213..LHD..4D) 45

#	OEM	Part name
53272	53272-26011	Bracket, Headlamp Mounting, Lh
53828	53827-26010	Protector, Front Fender Side Panel, Rh
55706	55706-26050	Panel Sub-Assy, Cowl Top Side, Lh
58448	58448-26010-B0	Hook, Engine Service Hole Cover, No.2 Lh
61024	61024-26130	Pillar Sub-Assy, Front Body, Inner Lh
61038	61038-26020	Reinforcement Sub-Assy, Center Body Pillar, Lh
61109	61109-26010	Reinforce Sub-Assy, Front Body Pillar, Lower Lh
61112	61112-26351	Panel, Front Side, Outer Lh
61132	61132-26121	Pillar, Front Body, Outer Lh
61144	61144-26010	Retainer, Front Bumper Side, Lh
61242	61242-26010	Gusset, Roof Side Rail, Rear Lh
61249	61249-26020	Retainer, Roof Side Rail, Outer Lh
61262	61262-26021	Channel, Roof Drip, Lh
61348	61348-26050	Reinforcement, Belt Anchor To Center Pillar, Lh
61416	61416-26021	Panel, Front Step Under, Lh
61424	61424-26030	Panel, Fender, Inner Lower Lh
61484	61481-26080	Bracket, Roof Side Rail Reinforce, No.4
61512	61512-26040	Pillar, Quarter Lock, Lh
61528	61528-26040	Reinforcement, Quarter Lock Piller, Lower Lh
61578	61578-26030	Plate, Cab Rear Pillar, Lower Lh
61604	61620-26300	Panel Sub-Assy, Quarter Wheel House, Lh
61604	61620-26310	Panel Sub-Assy, Quarter Wheel House, Lh
61612	61612-26540	Panel, Quarter, Lh
61612	61612-26610	Panel, Quarter, Lh
61614	61614-26G10	Panel, Quarter, Inner Lh
61616	61616-26120	Reinforcement, Rear Body Rear Side Panel, Lh
61634	61604-26020	Panel, Quarter Wheel House, Inner Lh
61636	61636-26040	Reinforcement, Quarter Panel, Upr Lh
61638	61638-26030	Reinforcement, Quarter, Inner Lh
61686	61686-26010	Bracket, Rear Seat Back Stopper, Lh
61706	61706-26270	Frame Sub-Assy, Back Door Opening Side, Lh
61718	61718-26040	Reinforcement, Quarter Panel Extension, Lh
61725	61725-26041	Box, Fuel Inlet
61736	61736-26A40	Extension, Quarter Panel, Inner Lh
61739	61739-26040	Reinforcement, Extension Quarter Inner Panel
61746	61746-26040	Reinforcement, Back Door Opening, Lower Lh
61748	61748-26010	Brace, Roof Side Inner To Wheel House, Lh
61762	61762-26020	Reinforce, Seat Belt Anchor, No.1 Upper Lh
61774	61774-26140	Frame, Back Door Opening Side, Upper Lh
64126	64126-26030	Anchor, Pillar Seat Belt, Lh
64162	64162-26010	Bracket, Fuel Inlet
77358	77358-26010	Stopper, Fuel Filler Opening Lid, No.1
9015460043	90154-60043	SCREW CROSSRECESS
9026903002	90269-03002	RIVET
9054115030	90541-15030	Cushion, Luggage Door Hinge

OEM	Part name	Category
53272-26011	Bracket, Headlamp Mounting, Lh	Side Member ([12.2013 - ] LH (1312- )KDH21#,LH212,TRH213..LHD..4D)
53827-26010	Protector, Front Fender Side Panel, Rh	Side Member ([12.2013 - ] LH (1312- )KDH21#,LH212,TRH213..LHD..4D)
55706-26050	Panel Sub-Assy, Cowl Top Side, Lh	Side Member ([12.2013 - ] LH (1312- )KDH21#,LH212,TRH213..LHD..4D)
58448-26010-B0	Hook, Engine Service Hole Cover, No.2 Lh	Side Member ([12.2013 - ] LH (1312- )KDH21#,LH212,TRH213..LHD..4D)
61024-26130	Pillar Sub-Assy, Front Body, Inner Lh	Side Member ([12.2013 - ] LH (1312- )KDH21#,LH212,TRH213..LHD..4D)
61038-26020	Reinforcement Sub-Assy, Center Body Pillar, Lh	Side Member ([12.2013 - ] LH (1312- )KDH21#,LH212,TRH213..LHD..4D)
61109-26010	Reinforce Sub-Assy, Front Body Pillar, Lower Lh	Side Member ([12.2013 - ] LH (1312- )KDH21#,LH212,TRH213..LHD..4D)
61112-26351	Panel, Front Side, Outer Lh	Side Member ([12.2013 - ] LH (1312- )KDH21#,LH212,TRH213..LHD..4D)
61132-26121	Pillar, Front Body, Outer Lh	Side Member ([12.2013 - ] LH (1312- )KDH21#,LH212,TRH213..LHD..4D)
61144-26010	Retainer, Front Bumper Side, Lh	Side Member ([12.2013 - ] LH (1312- )KDH21#,LH212,TRH213..LHD..4D)
61242-26010	Gusset, Roof Side Rail, Rear Lh	Side Member ([12.2013 - ] LH (1312- )KDH21#,LH212,TRH213..LHD..4D)
61249-26020	Retainer, Roof Side Rail, Outer Lh	Side Member ([12.2013 - ] LH (1312- )KDH21#,LH212,TRH213..LHD..4D)
61262-26021	Channel, Roof Drip, Lh	Side Member ([12.2013 - ] LH (1312- )KDH21#,LH212,TRH213..LHD..4D)
61348-26050	Reinforcement, Belt Anchor To Center Pillar, Lh	Side Member ([12.2013 - ] LH (1312- )KDH21#,LH212,TRH213..LHD..4D)
61416-26021	Panel, Front Step Under, Lh	Side Member ([12.2013 - ] LH (1312- )KDH21#,LH212,TRH213..LHD..4D)
61424-26030	Panel, Fender, Inner Lower Lh	Side Member ([12.2013 - ] LH (1312- )KDH21#,LH212,TRH213..LHD..4D)
61481-26080	Bracket, Roof Side Rail Reinforce, No.4	Side Member ([12.2013 - ] LH (1312- )KDH21#,LH212,TRH213..LHD..4D)
61512-26040	Pillar, Quarter Lock, Lh	Side Member ([12.2013 - ] LH (1312- )KDH21#,LH212,TRH213..LHD..4D)
61528-26040	Reinforcement, Quarter Lock Piller, Lower Lh	Side Member ([12.2013 - ] LH (1312- )KDH21#,LH212,TRH213..LHD..4D)
61578-26030	Plate, Cab Rear Pillar, Lower Lh	Side Member ([12.2013 - ] LH (1312- )KDH21#,LH212,TRH213..LHD..4D)
61604-26020	Panel, Quarter Wheel House, Inner Lh	Side Member ([12.2013 - ] LH (1312- )KDH21#,LH212,TRH213..LHD..4D)
61612-26540	Panel, Quarter, Lh	Side Member ([12.2013 - ] LH (1312- )KDH21#,LH212,TRH213..LHD..4D)
61612-26610	Panel, Quarter, Lh	Side Member ([12.2013 - ] LH (1312- )KDH21#,LH212,TRH213..LHD..4D)
61614-26G10	Panel, Quarter, Inner Lh	Side Member ([12.2013 - ] LH (1312- )KDH21#,LH212,TRH213..LHD..4D)
61616-26120	Reinforcement, Rear Body Rear Side Panel, Lh	Side Member ([12.2013 - ] LH (1312- )KDH21#,LH212,TRH213..LHD..4D)
61620-26300	Panel Sub-Assy, Quarter Wheel House, Lh	Side Member ([12.2013 - ] LH (1312- )KDH21#,LH212,TRH213..LHD..4D)
61620-26310	Panel Sub-Assy, Quarter Wheel House, Lh	Side Member ([12.2013 - ] LH (1312- )KDH21#,LH212,TRH213..LHD..4D)
61636-26040	Reinforcement, Quarter Panel, Upr Lh	Side Member ([12.2013 - ] LH (1312- )KDH21#,LH212,TRH213..LHD..4D)
61638-26030	Reinforcement, Quarter, Inner Lh	Side Member ([12.2013 - ] LH (1312- )KDH21#,LH212,TRH213..LHD..4D)
61686-26010	Bracket, Rear Seat Back Stopper, Lh	Side Member ([12.2013 - ] LH (1312- )KDH21#,LH212,TRH213..LHD..4D)
61706-26270	Frame Sub-Assy, Back Door Opening Side, Lh	Side Member ([12.2013 - ] LH (1312- )KDH21#,LH212,TRH213..LHD..4D)
61718-26040	Reinforcement, Quarter Panel Extension, Lh	Side Member ([12.2013 - ] LH (1312- )KDH21#,LH212,TRH213..LHD..4D)
61725-26041	Box, Fuel Inlet	Side Member ([12.2013 - ] LH (1312- )KDH21#,LH212,TRH213..LHD..4D)
61736-26A40	Extension, Quarter Panel, Inner Lh	Side Member ([12.2013 - ] LH (1312- )KDH21#,LH212,TRH213..LHD..4D)
61739-26040	Reinforcement, Extension Quarter Inner Panel	Side Member ([12.2013 - ] LH (1312- )KDH21#,LH212,TRH213..LHD..4D)
61746-26040	Reinforcement, Back Door Opening, Lower Lh	Side Member ([12.2013 - ] LH (1312- )KDH21#,LH212,TRH213..LHD..4D)
61748-26010	Brace, Roof Side Inner To Wheel House, Lh	Side Member ([12.2013 - ] LH (1312- )KDH21#,LH212,TRH213..LHD..4D)
61762-26020	Reinforce, Seat Belt Anchor, No.1 Upper Lh	Side Member ([12.2013 - ] LH (1312- )KDH21#,LH212,TRH213..LHD..4D)
61774-26140	Frame, Back Door Opening Side, Upper Lh	Side Member ([12.2013 - ] LH (1312- )KDH21#,LH212,TRH213..LHD..4D)
64126-26030	Anchor, Pillar Seat Belt, Lh	Side Member ([12.2013 - ] LH (1312- )KDH21#,LH212,TRH213..LHD..4D)
64162-26010	Bracket, Fuel Inlet	Side Member ([12.2013 - ] LH (1312- )KDH21#,LH212,TRH213..LHD..4D)
77358-26010	Stopper, Fuel Filler Opening Lid, No.1	Side Member ([12.2013 - ] LH (1312- )KDH21#,LH212,TRH213..LHD..4D)
90154-60043	SCREW CROSSRECESS	Side Member ([12.2013 - ] LH (1312- )KDH21#,LH212,TRH213..LHD..4D)
90269-03002	RIVET	Side Member ([12.2013 - ] LH (1312- )KDH21#,LH212,TRH213..LHD..4D)
90541-15030	Cushion, Luggage Door Hinge	Side Member ([12.2013 - ] LH (1312- )KDH21#,LH212,TRH213..LHD..4D)

Source: Public OEM parts-catalog data
Variants: 2 / 4
Category: 213
Collected: 2026-08-03
