| 11101-88400 |
Head Sub-Assy, Cylinder |
Cylinder Head ([08.1990 - ] (9008- )1JZGTE) |
| 11115-88400 |
Gasket, Cylinder Head |
Cylinder Head ([08.1990 - ] (9008- )1JZGTE) |
| 11115-88410 |
Gasket, Cylinder Head |
Cylinder Head ([08.1990 - ] (9008- )1JZGTE) |
| 11122-88400 |
Bush, Intake Valve Guide |
Cylinder Head ([08.1990 - ] (9008- )1JZGTE) |
| 11123-88400 |
Bush, Intake Valve Guide |
Cylinder Head ([08.1990 - ] (9008- )1JZGTE) |
| 11131-46030 |
Seat, Intake Valve |
Cylinder Head ([08.1990 - ] (9008- )1JZGTE) |
| 11132-46030 |
Seat, Intake Valve |
Cylinder Head ([08.1990 - ] (9008- )1JZGTE) |
| 11135-46030 |
Seat, Exhaust Valve |
Cylinder Head ([08.1990 - ] (9008- )1JZGTE) |
| 11136-46030 |
Seat, Exhaust Valve |
Cylinder Head ([08.1990 - ] (9008- )1JZGTE) |
| 11183-88400 |
Plug, Semicircular |
Cylinder Head ([08.1990 - ] (9008- )1JZGTE) |
| 11201-88400 |
Cover Sub-Assy, Cylinder Head |
Cylinder Head ([08.1990 - ] (9008- )1JZGTE) |
| 11202-88400 |
Cover Sub-Assy, Cylinder Head |
Cylinder Head ([08.1990 - ] (9008- )1JZGTE) |
| 11213-88400 |
Gasket, Cylinder Head Cover |
Cylinder Head ([08.1990 - ] (9008- )1JZGTE) |
| 11219-88400 |
Cover, Cylinder Head, No.3 |
Cylinder Head ([08.1990 - ] (9008- )1JZGTE) |
| 12180-46010 |
Cap Sub-Assy, Oil Filler |
Cylinder Head ([08.1990 - ] (9008- )1JZGTE) |
| 12195-46010 |
Gasket(For Oil Filler Cap) |
Cylinder Head ([08.1990 - ] (9008- )1JZGTE) |
| 12195-46011 |
Gasket(For Oil Filler Cap) |
Cylinder Head ([08.1990 - ] (9008- )1JZGTE) |
| 90105-06133 |
Bolt |
Cylinder Head ([08.1990 - ] (9008- )1JZGTE) |
| 90110-06010 |
BOLT, HEXAGON SOCKET |
Cylinder Head ([08.1990 - ] (9008- )1JZGTE) |
| 90119-08890 |
Bolt(For Head To Camshaft Bearing Cap) |
Cylinder Head ([08.1990 - ] (9008- )1JZGTE) |
| 90201-11018 |
Washer, Plate(For Cylinder Head Set) |
Cylinder Head ([08.1990 - ] (9008- )1JZGTE) |
| 90201-11034 |
Washer, Plate(For Cylinder Head Set) |
Cylinder Head ([08.1990 - ] (9008- )1JZGTE) |
| 90210-07001 |
Washer, Seal(For Cylinder Head Cover) |
Cylinder Head ([08.1990 - ] (9008- )1JZGTE) |
| 90253-11021 |
Pin, Ring |
Cylinder Head ([08.1990 - ] (9008- )1JZGTE) |
| 90341-18010 |
Plug, W/head Straight Screw, No.1 |
Cylinder Head ([08.1990 - ] (9008- )1JZGTE) |
| 90341-27003 |
Plug, W/head Taper Screw, No.1 |
Cylinder Head ([08.1990 - ] (9008- )1JZGTE) |
| 90910-02102 |
Bolt(For Cylinder Head Set) |
Cylinder Head ([08.1990 - ] (9008- )1JZGTE) |
| 90919-05007 |
Sensor, Cam Position |
Cylinder Head ([08.1990 - ] (9008- )1JZGTE) |
| 91511-60616 |
BOLTFLANGE |
Cylinder Head ([08.1990 - ] (9008- )1JZGTE) |
| 91511-B0616 |
BOLT, FLANGE |
Cylinder Head ([08.1990 - ] (9008- )1JZGTE) |
