Search › Model › JB416X
JB416X
Vacuum tank (TYPE 4:JB419XD) 5
| # | OEM | Part name |
|---|---|---|
| 1 | 18130-67JG1-000 | PUMP ASSY,VACUUM |
| 2 | 18139-67JG0-000 | GASKET,VACUUM PUMP |
| 3 | 13532-84A01-000 | BOLT,8X22 |
| 4 | 09250-04003-000 | PLUG(OD:8) - Plug (od:8) |
| 4 | 07130-0510B-000 | Bolt - Bolt, sensor |
| OEM | Part name | Category |
|---|---|---|
| 07130-0510B-000 | Bolt - Bolt, sensor | Vacuum tank (TYPE 4:JB419XD) |
| 09250-04003-000 | PLUG(OD:8) - Plug (od:8) | Vacuum tank (TYPE 4:JB419XD) |
| 13532-84A01-000 | BOLT,8X22 | Vacuum tank (TYPE 4:JB419XD) |
| 18130-67JG1-000 | PUMP ASSY,VACUUM | Vacuum tank (TYPE 4:JB419XD) |
| 18139-67JG0-000 | GASKET,VACUUM PUMP | Vacuum tank (TYPE 4:JB419XD) |
