| 01570-08253-000 |
Bolt, upper |
front axle (C,V; 1997-05-01~1998-10-01) |
| 01570-0825A-000 |
Bolt |
front axle (C,V; 1997-05-01~1998-10-01) |
| 01570-0825B-000 |
Bolt |
front axle (C,V; 1997-05-01~1998-10-01) |
| 02122-04083-000 |
SCREW |
front axle (C,V; 1997-05-01~1998-10-01) |
| 02122-0408A-000 |
SCREW |
front axle (C,V; 1997-05-01~1998-10-01) |
| 09117-08050-000 |
BOLT(8X20) |
front axle (C,V; 1997-05-01~1998-10-01) |
| 09119-12012-000 |
BOLT(12X38) |
front axle (C,V; 1997-05-01~1998-10-01) |
| 09265-15005-000 |
BEARING(15X42X14.25) |
front axle (C,V; 1997-05-01~1998-10-01) |
| 09267-41001-000 |
ベアリング,41X68X40 |
front axle (C,V; 1997-05-01~1998-10-01) |
| 09283-26016-000 |
SEAL,OIL(26X38X8) |
front axle (C,V; 1997-05-01~1998-10-01) |
| 09283-54001-000 |
SEAL,OIL(54X69X7) |
front axle (C,V; 1997-05-01~1998-10-01) |
| 09285-00002-000 |
SEAL,OIL(85X112X5) |
front axle (C,V; 1997-05-01~1998-10-01) |
| 09380-26004-000 |
CIRCLIP |
front axle (C,V; 1997-05-01~1998-10-01) |
| 09381-68001-000 |
CIRCLIP |
front axle (C,V; 1997-05-01~1998-10-01) |
| 43420-51830-000 |
HUB SET,FR WHL |
front axle (C,V; 1997-05-01~1998-10-01) |
| 43440-60A03-000 |
SPINDLE,FR WHEEL |
front axle (C,V; 1997-05-01~1998-10-01) |
| 43445-60A11-000 |
BUSHING,FR SPINDLE |
front axle (C,V; 1997-05-01~1998-10-01) |
| 43461-60A01-000 |
NUT,FR WHL BRG LOCK |
front axle (C,V; 1997-05-01~1998-10-01) |
| 43462-84A00-000 |
BEARING,FR WHEEL |
front axle (C,V; 1997-05-01~1998-10-01) |
| 43465-60A00-000 |
WASHER,FR WHEEL BRG |
front axle (C,V; 1997-05-01~1998-10-01) |
| 43466-60A00-000 |
WASHER,FR WHEEL BRG LOCK |
front axle (C,V; 1997-05-01~1998-10-01) |
| 43800-60811-000 |
HUB ASSY LOCKING MANUAL |
front axle (C,V; 1997-05-01~1998-10-01) |
| 43800-60812-000 |
WHEEL LOCKING HUB SET (MANUAL) |
front axle (C,V; 1997-05-01~1998-10-01) |
| 43813-60A00-000 |
GASKET,LOCKING HUB COVER |
front axle (C,V; 1997-05-01~1998-10-01) |
| 43814-60A01-000 |
BOLT,LOCKING HUB COVER |
front axle (C,V; 1997-05-01~1998-10-01) |
| 43838-60A00-000 |
O-RING |
front axle (C,V; 1997-05-01~1998-10-01) |
| 43841-80001-000 |
WASHER,LOCKING HUB CONE |
front axle (C,V; 1997-05-01~1998-10-01) |
| 44101-80050-000 |
ジョイントアッシ,フロントアクスルシャフト,ライト |
front axle (C,V; 1997-05-01~1998-10-01) |
| 44102-80050-000 |
ジョイントアッシ,フロントアクスルシャフト,レフト |
front axle (C,V; 1997-05-01~1998-10-01) |
| 44182-60A01-000 |
WASHER,FR SPINDLE THRUST |
front axle (C,V; 1997-05-01~1998-10-01) |
| 45111-82CA0-000 |
KNUCKLE,STEERING,R |
front axle (C,V; 1997-05-01~1998-10-01) |
| 45151-82CA0-000 |
Knuckle,steering,l |
front axle (C,V; 1997-05-01~1998-10-01) |
| 45600-82810-000 |
Pad set |
front axle (C,V; 1997-05-01~1998-10-01) |
| 45610-63002-000 |
PIN ASSY,KING |
front axle (C,V; 1997-05-01~1998-10-01) |
| 45621-63000-000 |
SHIM,KINGPIN NO.1 (T=0.5) |
front axle (C,V; 1997-05-01~1998-10-01) |
| 45622-63000-000 |
SHIM,KINGPIN NO.2 (T=0.1) |
front axle (C,V; 1997-05-01~1998-10-01) |
| 45623-80001-000 |
RETAINER,OIL SEAL |
front axle (C,V; 1997-05-01~1998-10-01) |
| 45625-63001-000 |
COVER,OIL SEAL |
front axle (C,V; 1997-05-01~1998-10-01) |
| 45626-83000-000 |
BOLT,JOINT SEAL |
front axle (C,V; 1997-05-01~1998-10-01) |
| 94412-31J01-YMC |
Cowling,body Lower |
front axle (C,V; 1997-05-01~1998-10-01) |
