Search › Model › GYL20

GYL20

Lexus RX · 2015 · 7,108 parts · 368 categories

7,108 items

Wiring & Clamp ([10.2015 - ] DOOR (1510- )) 20

#	OEM	Part name
82151	82151-0E290	Wire, Front Door, Rh
82151	82151-0E330	Wire, Front Door, Rh
82151	82151-0E340	Wire, Front Door, Rh
82152	82152-0E290	Wire, Front Door, Lh
82152	82152-0E300	Wire, Front Door, Lh
82152	82152-0E310	Wire, Front Door, Lh
82153	82153-0E060	Wire, Rear Door, No.1
82153	82153-0E120	Wire, Rear Door, No.1
82153	82157-0E010	Wire, Rear Door, Rh
82153	82157-0E030	Wire, Rear Door, Rh
82154	82154-0E060	Wire, Rear Door, No.2
82154	82154-0E120	Wire, Rear Door, No.2
82181	82181-0E200	Wire, Luggage Room, No.1
82182	82182-0E060	Wire, Luggage Room, No.2
82183	82183-0E060	Wire, Luggage Room, No.3
82184	82184-0E470	Wire, Back Door, No.1
82184	82184-0E490	Wire, Back Door, No.1
82184	82184-0E491	Wire, Back Door, No.1
82712	82712-48120	Support, Wiring Harness
9008011545	90080-11545	New Genuine Part

OEM	Part name	Category
82151-0E290	Wire, Front Door, Rh	Wiring & Clamp ([10.2015 - ] DOOR (1510- ))
82151-0E330	Wire, Front Door, Rh	Wiring & Clamp ([10.2015 - ] DOOR (1510- ))
82151-0E340	Wire, Front Door, Rh	Wiring & Clamp ([10.2015 - ] DOOR (1510- ))
82152-0E290	Wire, Front Door, Lh	Wiring & Clamp ([10.2015 - ] DOOR (1510- ))
82152-0E300	Wire, Front Door, Lh	Wiring & Clamp ([10.2015 - ] DOOR (1510- ))
82152-0E310	Wire, Front Door, Lh	Wiring & Clamp ([10.2015 - ] DOOR (1510- ))
82153-0E060	Wire, Rear Door, No.1	Wiring & Clamp ([10.2015 - ] DOOR (1510- ))
82153-0E120	Wire, Rear Door, No.1	Wiring & Clamp ([10.2015 - ] DOOR (1510- ))
82154-0E060	Wire, Rear Door, No.2	Wiring & Clamp ([10.2015 - ] DOOR (1510- ))
82154-0E120	Wire, Rear Door, No.2	Wiring & Clamp ([10.2015 - ] DOOR (1510- ))
82157-0E010	Wire, Rear Door, Rh	Wiring & Clamp ([10.2015 - ] DOOR (1510- ))
82157-0E030	Wire, Rear Door, Rh	Wiring & Clamp ([10.2015 - ] DOOR (1510- ))
82181-0E200	Wire, Luggage Room, No.1	Wiring & Clamp ([10.2015 - ] DOOR (1510- ))
82182-0E060	Wire, Luggage Room, No.2	Wiring & Clamp ([10.2015 - ] DOOR (1510- ))
82183-0E060	Wire, Luggage Room, No.3	Wiring & Clamp ([10.2015 - ] DOOR (1510- ))
82184-0E470	Wire, Back Door, No.1	Wiring & Clamp ([10.2015 - ] DOOR (1510- ))
82184-0E490	Wire, Back Door, No.1	Wiring & Clamp ([10.2015 - ] DOOR (1510- ))
82184-0E491	Wire, Back Door, No.1	Wiring & Clamp ([10.2015 - ] DOOR (1510- ))
82712-48120	Support, Wiring Harness	Wiring & Clamp ([10.2015 - ] DOOR (1510- ))
90080-11545	New Genuine Part	Wiring & Clamp ([10.2015 - ] DOOR (1510- ))
