| 82210-0C030 |
Harness Assy, Air Conditioner, No.2 |
Heating & Air Conditioning - Cooler Unit ([12.2013 - ] REAR,AIR CONDITIONER (1312- )) |
| 87030-0E030 |
Unit Assy, Cooling, Rear |
Heating & Air Conditioning - Cooler Unit ([12.2013 - ] REAR,AIR CONDITIONER (1312- )) |
| 87103-0C061 |
Motor Sub-Assy, Blower W/fan(For Rear) |
Heating & Air Conditioning - Cooler Unit ([12.2013 - ] REAR,AIR CONDITIONER (1312- )) |
| 87106-0C130 |
Damper Servo Sub-Assy, Rear Cooling Unit, No.2 - DAMPER(FOR AIRMIX REAR) |
Heating & Air Conditioning - Cooler Unit ([12.2013 - ] REAR,AIR CONDITIONER (1312- )) |
| 87106-0E160 |
Servo Sub-Assy, Damper(For Mode Rear) |
Heating & Air Conditioning - Cooler Unit ([12.2013 - ] REAR,AIR CONDITIONER (1312- )) |
| 87107-0E030 |
Unit Sub-Assy, Heater Radiator |
Heating & Air Conditioning - Cooler Unit ([12.2013 - ] REAR,AIR CONDITIONER (1312- )) |
| 87165-28020 |
Control, Blower Motor |
Heating & Air Conditioning - Cooler Unit ([12.2013 - ] REAR,AIR CONDITIONER (1312- )) |
| 87193-87101 |
SCREW TAPPING |
Heating & Air Conditioning - Cooler Unit ([12.2013 - ] REAR,AIR CONDITIONER (1312- )) |
| 87207-0E040 |
Pipe Sub-Assy, Water |
Heating & Air Conditioning - Cooler Unit ([12.2013 - ] REAR,AIR CONDITIONER (1312- )) |
| 88501-0C080 |
Evaporator Sub-Assy (Rear) |
Heating & Air Conditioning - Cooler Unit ([12.2013 - ] REAR,AIR CONDITIONER (1312- )) |
| 88515-0E110 |
Valve, Rear Cooling Unit Expansion |
Heating & Air Conditioning - Cooler Unit ([12.2013 - ] REAR,AIR CONDITIONER (1312- )) |
| 88539-0E060 |
Hose, Drain Cooler |
Heating & Air Conditioning - Cooler Unit ([12.2013 - ] REAR,AIR CONDITIONER (1312- )) |
| 88578-0E060 |
Packing, Cooling Unit, No.2 |
Heating & Air Conditioning - Cooler Unit ([12.2013 - ] REAR,AIR CONDITIONER (1312- )) |
| 88578-0E080 |
Paking, Cooler Air Duct |
Heating & Air Conditioning - Cooler Unit ([12.2013 - ] REAR,AIR CONDITIONER (1312- )) |
| 88578-0E090 |
Paking, Cooler Air Duct |
Heating & Air Conditioning - Cooler Unit ([12.2013 - ] REAR,AIR CONDITIONER (1312- )) |
| 88710-0E270 |
Tube & Accessory Assy, Air Conditioner |
Heating & Air Conditioning - Cooler Unit ([12.2013 - ] REAR,AIR CONDITIONER (1312- )) |
| 88892-0C030 |
Cover Sub-Assy |
Heating & Air Conditioning - Cooler Unit ([12.2013 - ] REAR,AIR CONDITIONER (1312- )) |
| 90069-08007 |
AC ORING |
Heating & Air Conditioning - Cooler Unit ([12.2013 - ] REAR,AIR CONDITIONER (1312- )) |
| 90069-08009 |
GASKET |
Heating & Air Conditioning - Cooler Unit ([12.2013 - ] REAR,AIR CONDITIONER (1312- )) |
| 90069-08011 |
AC ORING |
Heating & Air Conditioning - Cooler Unit ([12.2013 - ] REAR,AIR CONDITIONER (1312- )) |
| 90099-00264 |
SCREW |
Heating & Air Conditioning - Cooler Unit ([12.2013 - ] REAR,AIR CONDITIONER (1312- )) |
| 90099-00318 |
New Genuine Part |
Heating & Air Conditioning - Cooler Unit ([12.2013 - ] REAR,AIR CONDITIONER (1312- )) |
| 90099-00968 |
Screw(For Air Conditioner Unit) |
Heating & Air Conditioning - Cooler Unit ([12.2013 - ] REAR,AIR CONDITIONER (1312- )) |
| 90119-06911 |
BOLT WWASHER |
Heating & Air Conditioning - Cooler Unit ([12.2013 - ] REAR,AIR CONDITIONER (1312- )) |
| 90480-26030 |
Grommet (For Cooler Unit Drain Hose) |
Heating & Air Conditioning - Cooler Unit ([12.2013 - ] REAR,AIR CONDITIONER (1312- )) |
| 96134-42100 |
Clip(For Water By-Pass Hose Assy) |
Heating & Air Conditioning - Cooler Unit ([12.2013 - ] REAR,AIR CONDITIONER (1312- )) |
