GRMN86
Rear Spring & Shock Absorber ([02.2016 - ] (1602- )) 7
| # | OEM | Part name |
|---|---|---|
| 48231 | 48231-18020 | Spring, Coil, Rear Rh |
| 48341 | 48341-18010 | Bumper, Rear Spring, No.1 Rh |
| 48530 | 48530-18040 | Absorber Assy, Shock, Rear Rh |
| 48530 | 90560-10019 | Spacer(For Pump Bracket, Front) |
| 48705 | 48705-18010 | Link Sub-Assy, Toe Control, Rh |
| 48812 | 48812-18010 | Bar, Stabilizer, Rear |
| 9020114020 | 90201-14020 | WASHER |
| OEM | Part name | Category |
|---|---|---|
| 48231-18020 | Spring, Coil, Rear Rh | Rear Spring & Shock Absorber ([02.2016 - ] (1602- )) |
| 48341-18010 | Bumper, Rear Spring, No.1 Rh | Rear Spring & Shock Absorber ([02.2016 - ] (1602- )) |
| 48530-18040 | Absorber Assy, Shock, Rear Rh | Rear Spring & Shock Absorber ([02.2016 - ] (1602- )) |
| 48705-18010 | Link Sub-Assy, Toe Control, Rh | Rear Spring & Shock Absorber ([02.2016 - ] (1602- )) |
| 48812-18010 | Bar, Stabilizer, Rear | Rear Spring & Shock Absorber ([02.2016 - ] (1602- )) |
| 90201-14020 | WASHER | Rear Spring & Shock Absorber ([02.2016 - ] (1602- )) |
| 90560-10019 | Spacer(For Pump Bracket, Front) | Rear Spring & Shock Absorber ([02.2016 - ] (1602- )) |
