GRMN86
Disc Wheel & Wheel Cap ([02.2016 - ] (1602- )) 9
| # | OEM | Part name |
|---|---|---|
| 42601 | 42611-18050 | Wheel, Disc (For Front) |
| 42601 | 42611-18060 | Wheel, Disc (For Rear) |
| 42603 | 42603-52160 | Ornament Sub-Assy, Wheel Hub |
| 42611 | 90942-05028 | Valve (For Tubeless Tire) |
| 42611 | 90942-05029 | Cap, Tire Valve |
| 9094203264 | 90942-03264 | New Genuine Part |
| 9094203265 | 90942-03265 | WEIGHT BALANCE |
| 9094203267 | 90942-03267 | WEIGHT BALANCE |
| 9094203273 | 90942-03273 | WEIGHT BALANCE |
| OEM | Part name | Category |
|---|---|---|
| 42603-52160 | Ornament Sub-Assy, Wheel Hub | Disc Wheel & Wheel Cap ([02.2016 - ] (1602- )) |
| 42611-18050 | Wheel, Disc (For Front) | Disc Wheel & Wheel Cap ([02.2016 - ] (1602- )) |
| 42611-18060 | Wheel, Disc (For Rear) | Disc Wheel & Wheel Cap ([02.2016 - ] (1602- )) |
| 90942-03264 | New Genuine Part | Disc Wheel & Wheel Cap ([02.2016 - ] (1602- )) |
| 90942-03265 | WEIGHT BALANCE | Disc Wheel & Wheel Cap ([02.2016 - ] (1602- )) |
| 90942-03267 | WEIGHT BALANCE | Disc Wheel & Wheel Cap ([02.2016 - ] (1602- )) |
| 90942-03273 | WEIGHT BALANCE | Disc Wheel & Wheel Cap ([02.2016 - ] (1602- )) |
| 90942-05028 | Valve (For Tubeless Tire) | Disc Wheel & Wheel Cap ([02.2016 - ] (1602- )) |
| 90942-05029 | Cap, Tire Valve | Disc Wheel & Wheel Cap ([02.2016 - ] (1602- )) |
