| 80050-SP0-000 |
Label - AIR CONDITIONER CAUTION (HFC134A) |
Air conditioner (HOSES/PIPES; RH) |
| 80311-S2H-003 |
Hose comp. - SUCTION |
Air conditioner (HOSES/PIPES; RH) |
| 80315-S2H-003 |
Hose comp. - DISCHARGE |
Air conditioner (HOSES/PIPES; RH) |
| 80331-S2H-003 |
Pipe - CONDENSER |
Air conditioner (HOSES/PIPES; RH) |
| 80341-S2H-003 |
Pipe - RECEIVER |
Air conditioner (HOSES/PIPES; RH) |
| 80351-S2H-003 |
Receiver comp |
Air conditioner (HOSES/PIPES; RH) |
| 80352-S04-000 |
Bracket - LIQUID TANK |
Air conditioner (HOSES/PIPES; RH) |
| 80361-S2G-000 |
Stay - SUCTION HOSE |
Air conditioner (HOSES/PIPES; RH) |
| 80381-SV7-A01 |
Clamp - RECEIVER PIPE |
Air conditioner (HOSES/PIPES; RH) |
| 80440-SW5-003 |
Switch - DUAL PRESSURE (HADSYS) |
Air conditioner (HOSES/PIPES; RH) |
| 80440-SW5-A01 |
Switch - DUAL PRESSURE(KEIHIN) |
Air conditioner (HOSES/PIPES; RH) |
| 80865-SL0-003 |
Cap - VALVE (H) |
Air conditioner (HOSES/PIPES; RH) |
| 80866-ST0-003 |
Cap l - VALVE (NICHIRIN) |
Air conditioner (HOSES/PIPES; RH) |
| 80871-S50-000 |
O-ring - 5/8" |
Air conditioner (HOSES/PIPES; RH) |
| 80871-S5A-003 |
O-ring - 5/8" |
Air conditioner (HOSES/PIPES; RH) |
| 80872-S50-000 |
O-ring - 1/2" |
Air conditioner (HOSES/PIPES; RH) |
| 80872-S5A-003 |
O-ring - 1/2" |
Air conditioner (HOSES/PIPES; RH) |
| 80873-S50-000 |
O-ring - 8MM |
Air conditioner (HOSES/PIPES; RH) |
| 91548-SR3-003 |
Clip - 8MM |
Air conditioner (HOSES/PIPES; RH) |
