| 16008-52A00 |
Cover-Pump Diaphragm |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16011-47A06 |
Chamber Assy-Choke |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16033-23M20 |
Jet-Main |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16033-H8805 |
Jet-Main |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16036-11M03 |
Bleed-Main Air |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16036-52A00 |
Bleed-Main Air |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16037-52A00 |
Jet-Mixture |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16055-11M02 |
Jet-Slow |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16055-H8200 |
Jet-Slow |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16063-52A02 |
Cover-Gauge Lever |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16066-H7200 |
Shaft-Float |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16069-11M00 |
Spring-Injector |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16082-23M00 |
Plate-Adjust |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16098-01B00 |
Filter |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16101-33M12 |
Valve-Needle |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16116-12M04 |
Collar |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16125-61A04 |
Gauge-Level |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16127-18B00 |
Plate-Return |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16145-12M02 |
Screw |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16145-61A03 |
Spring-Screw Adjust |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16148-H1000 |
Spring-Return, Piston |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16171-11M00 |
Weight-Injector |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16176-47A05 |
Iacv-Ficd Solenoid Valve |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16196-52A01 |
Iacv-Ficd Solenoid Valve |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16198-18B00 |
Pin-Cotter |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16204-11M07 |
Bleed-Slow Air |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16204-H9501 |
Bleed-Slow Air |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16260-33M12 |
Throttle Position Switch |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16260-77A00 |
Throttle Position Switch |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16267-13M03 |
パイプ,ラバ- キヤブレ-タ- |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16267-52A00 |
Pipe-Rubber, Carburetor |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16267-52A04 |
Pipe-Rubber |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16273-08B06 |
Plate-Adjust |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16286-H7200 |
Plug |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16302-63A00 |
Lever-Pump |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16305-19915 |
Shaft-Pump Lever |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16307-77A00 |
Cover-Pump |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16313-47A05 |
Diaphragm Assy-Chamber |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16389-47A06 |
Cover-Thermo |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16390-47A06 |
Stopper-Cam |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16390-67A00 |
Plate-Thermo Cover |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16452-01B10 |
Spring-Pump Lever |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16453-H1000 |
Washer |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 17160-C0610 |
Packing |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
