EXY10

Toyota SERA · 1990 · 4,878 parts · 162 categories
EXY10 ×

← Back to categories

4,878 items
Switch & Relay & Computer ([03.1990 - ] (9003- )) 127
#OEMPart name
28300 28300-10020 Relay Assy, Starter
28300 28341-11010 Relay Assy, Starter
81980 81980-12070 Flasher Assy, Turn Signal
81980 81980-32010 Flasher Assy, Turn Signal
82600 90982-07011 Fuse, Fuse Block
82600 90982-08227 Fusible Link
82600 90982-09002 Fusible Link
82600 90982-09003 Fusible Link
82600 90982-09004 Fusible Link
82600 90982-09005 Fuse, Fuse Block
82616 82616-12020 Puller, Fuse
82650 82650-20011 Breaker Assy, Wiring Circuit, No.1
82660 82660-10110 Block Assy, Relay
82660 82660-10130 Block Assy, Relay
82661 82662-18020 Cover, Relay Block, No.1
82661 82662-18021 Cover, Relay Block, No.1
82661 82663-10010 Cover, Relay Block, No.1
82661 82663-10040 Cover, Relay Block, No.1
82661 82662-18010 Cover, Relay Block, No.1
82661 82662-18011 Cover, Relay Block, No.1
82671 82671-10020 Block, Junction
82671 82671-10021 Block, Junction
82672 82672-18010 Cover, Junction Block
82821 82821-20170 Cover, Connector
82821 82821-12250 Cover, Connector
82821 82821-12251 Cover, Connector
83320 83320-80163 Gage Assy, Fuel Sender
83420 83420-16020 Gage Assy, Water Temperature Sender
83530 83530-30080 Switch Assy, Oil Pressure (For Engine)
83530 83530-60040 Switch Assy, Oil Pressure (For Engine)
83530 83530-30090 Switch Assy, Oil Pressure (For Engine)
83530 83530-60020 Switch Assy, Oil Pressure (For Engine) - ＹＡＺＡＫＩ→ＤＥＮＳＯ
83650 90986-01005 Fusee
84052 84052-16020 Switch Assy, Un-Lock Warning
84052 84052-41010 Switch Assy, Un-Lock Warning
84110 84112-80059 Switch Assy, Light Control, No.1
84110 84112-80053 Switch Assy, Light Control, No.1
84140 84140-18010 Switch Assy, Headlamp Dimmer
84210 84210-12040 Switch Assy, Back-Up Lamp
84210 84210-52050 Switch Assy, Back-Up Lamp
84233 84231-22060 Switch Assy, Courtesy Lamp (For Front Door)
84233 84234-24010 Cushion, Courtesy Switch (For Front Door)
84310 84310-18011 Switch Assy, Turn Signal
84312 84312-10040 Plate, Horn Contact
84330 84332-18010 Switch Assy, Hazard Warning Signal
84330 84999-10320 Bulb, Satellite Switch
84330 84998-10240 Cap, Hazard Warning Switch Bulb
84340 84340-10020 Switch Assy, Stop Lamp
84340 84340-28010 Switch Assy, Stop Lamp
84340 84340-32090 Switch Assy, Stop Lamp
84340 84340-42010 Switch Assy, Stop Lamp
84450 84450-10110 Switch Assy, Ignition Or Starter
84540 84540-16030 Switch Assy, Neutral Start
84540 84540-16040 Switch Assy, Neutral Start
84550 84550-12060 Switch Assy, Parking Brake
84550 84550-18020 Switch Assy, Parking Brake
84650 84652-18010 Switch Assy, Windshield Wiper
84650 84652-16430 Switch Assy, Windshield Wiper
84722 84722-18010-03 Switch, Transmission Control
84722 84722-26080-B1 Switch, Transmission Control
84722 84722-18010-05 Switch, Transmission Control
84722 84722-18010-B0 Switch, Transmission Control
84727 84727-10010 Switch, Shift Lock Control
84730 84732-18010 Switch Assy, Heater Blower
84790 84790-18010 Switch Assy, Rear Window Defogger
84790 84998-10250 Cap, Bulb(For Rear Window Defogger Switch)
84790 84998-10300 Cap, Bulb(For Rear Window Defogger Switch)
84790 84998-10280 Cap, Multiplex Network Master Switch Bulb
84810 84810-18010 Switch Assy, Power Window Regulator
84820 84820-18010 Master Switch Assy, Power Window Regulator
84870 84870-18010 Switch Assy, Outer Mirror
84870 84870-32060-03 Switch Assy, Outer Mirror
84931 84931-18010 Switch, Door Control
85500 85500-18010 Lighter Assy, Cigarette
85500 85500-50020 Lighter Assy, Cigarette
85513 85513-12020 Cover, Cigarette Lighter
85515 85515-18010 Stay, Cigarette Lighter Bezel
85515 85515-20030 Stay, Cigarette Lighter Bezel
85912 90987-02008 Relay, Defogger
85915 90987-02006 Relay
85927 90987-03001 Relay
85933 85933-10010 Computer, Shift Lock Control
85980 85980-12130 Relay Assy, Door Control
85985 80590-18020 Relay, Key Reminder
85985 85985-18010 Relay, Key Reminder
85999 85999-18020 Bracket, Relay, No.3
85999 85999-18010 Bracket, Relay, No.2
85999 85999-18060 Bracket, Relay, No.4
85999 85999-18030 Bracket, Relay
86530 86530-20070 Relay Assy, Horn
88630 90987-02004 Relay Assy, Starter
88630 90987-04002 Relay, Ignition, No.1
89425 89425-19435 Sensor, Exhaust Gas Temperature
89425 89425-19495 Sensor, Exhaust Gas Temperature
89428 89428-12160 Switch, Temperature Detect, No.2
89428 89428-20060 Switch, Temperature Detect, No.2
89465 89465-10020 Sensor, Oxygen
89615 89615-22030 Sensor, Knock Control
89615 89615-22040 Sensor, Knock Control
89615 89615-35040 Sensor, Knock Control
89620 89621-12050 Igniter Assy
89620 89621-30010 Igniter Assy
89620 89621-12010 Igniter Assy
8271518090 82715-18090 Bracket,wiring Harness Clamp
9011906120 90119-06120 BOLT
9011906157 90119-06157 Bolt
9011906591 90119-06591 New Genuine Part
9014940013 90149-40013 New Genuine Part
9016750013 90167-50013 New Genuine Part
9016750013 93568-55014 Screw
9017906009 90179-06009 Nut (For Transmission Control Cable)
9017906009 90179-06156 Nut (For Transmission Control Cable)
9043008252 90430-08252 Gasket(For Catalytic Converter Sensor Guide)
9043018007 90430-18007 Gasket(For Water Hole)
9043018007 90430-18008 Gasket
9046400551 90464-00551 New Genuine Part
9165140620 91651-40620 BOLT
9165160616 91651-60616 BOLT
9311915010 93119-15010 New Genuine Part
9311915010 93219-15010 SCREW
9326954010 93269-54010 SCREW
9331514012 93315-14012 Screw with washer
9331913006 93319-13006 New Genuine Part
9331913008 93319-13008 New Genuine Part
9331914008 93319-14008 SCREW
9331915012 93319-15012 Screw
9354014012 93540-14012 Screw
