| 32133-SM4-003 |
Band - HARNESS OFFSET (30) (YELLOW) (122.5MM) |
Control unit (ENGINE ROOM; LH) |
| 32230-SR3-A01 |
Harness - ABS FUSE BOX |
Control unit (ENGINE ROOM; LH) |
| 38150-SR3-003 |
Horn assy - HIGH (MITSUBA) |
Control unit (ENGINE ROOM; LH) |
| 38211-SM4-003 |
Fuse - BLOCK (30A) |
Control unit (ENGINE ROOM; LH) |
| 38213-SM4-003 |
Fuse - BLOCK (50A) |
Control unit (ENGINE ROOM; LH) |
| 38216-SM4-003 |
Fuse - BLOCK (80A) |
Control unit (ENGINE ROOM; LH) |
| 38231-SR3-A00 |
Bracket - ABS FUSE BOX |
Control unit (ENGINE ROOM; LH) |
| 38232-SR3-A00 |
Stay - ABS COUPLER |
Control unit (ENGINE ROOM; LH) |
| 38250-SR2-G11 |
Box assy - MAIN FUSE |
Control unit (ENGINE ROOM; LH) |
| 38251-SR3-A00 |
Cover - UPPER |
Control unit (ENGINE ROOM; LH) |
| 38252-SR3-003 |
Cover - LOWER |
Control unit (ENGINE ROOM; LH) |
| 38253-SR2-G00 |
Label |
Control unit (ENGINE ROOM; LH) |
| 39792-SP0-014 |
Relay assy - POWER (4P) (MITSUBA) (12V NO) |
Control unit (ENGINE ROOM; LH) |
| 39794-SE0-003 |
Relay assy - POWER(4P)(DENSO) (056700-7250) |
Control unit (ENGINE ROOM; LH) |
| 39794-SL0-004 |
Relay assy - POWER(4P) (MITSUBA)(RC-2225)(BLACK) |
Control unit (ENGINE ROOM; LH) |
| 90129-SP0-000 |
Screw-washer - 5X12 |
Control unit (ENGINE ROOM; LH) |
| 90130-SR3-003 |
Bolt - 5X13 |
Control unit (ENGINE ROOM; LH) |
| 90153-SB2-003 |
Screw-washer - 5X10 |
Control unit (ENGINE ROOM; LH) |
