| 01570-06163-000 |
Bolt |
oil pan (C:4V:2WD:MT; 1997-04-01~1998-11-01) |
| 01570-0616A-000 |
Bolt |
oil pan (C:4V:2WD:MT; 1997-04-01~1998-11-01) |
| 01570-0616B-000 |
Bolt |
oil pan (C:4V:2WD:MT; 1997-04-01~1998-11-01) |
| 02162-06123-000 |
Bolt (6x12) |
oil pan (C:4V:2WD:MT; 1997-04-01~1998-11-01) |
| 02162-0612A-000 |
SCREW - Bolt, bracket |
oil pan (C:4V:2WD:MT; 1997-04-01~1998-11-01) |
| 02162-0612B-000 |
SCREW - Bolt |
oil pan (C:4V:2WD:MT; 1997-04-01~1998-11-01) |
| 08316-10063-000 |
Nut |
oil pan (C:4V:2WD:MT; 1997-04-01~1998-11-01) |
| 08316-1006B-000 |
NUT |
oil pan (C:4V:2WD:MT; 1997-04-01~1998-11-01) |
| 09108-06114-000 |
スタッドボルト |
oil pan (C:4V:2WD:MT; 1997-04-01~1998-11-01) |
| 09108-06114-XC0 |
BOLT,STUD |
oil pan (C:4V:2WD:MT; 1997-04-01~1998-11-01) |
| 09117-06033-000 |
BOLT(6X12) |
oil pan (C:4V:2WD:MT; 1997-04-01~1998-11-01) |
| 09168-14015-000 |
GASKET(14X20X1.5) - Gasket, oil hose union |
oil pan (C:4V:2WD:MT; 1997-04-01~1998-11-01) |
| 09247-14027-000 |
PLUG(14X11.5) - Plug, oil drain |
oil pan (C:4V:2WD:MT; 1997-04-01~1998-11-01) |
| 09247-14044-000 |
DRAIN PLUG (M14x1.5) |
oil pan (C:4V:2WD:MT; 1997-04-01~1998-11-01) |
| 09280-16005-000 |
O RING(D:2.4,ID:15.8) - O ring, exhaust pipe |
oil pan (C:4V:2WD:MT; 1997-04-01~1998-11-01) |
| 09401-30404-000 |
CLAMP - Clip |
oil pan (C:4V:2WD:MT; 1997-04-01~1998-11-01) |
| 11510-60C06-000 |
PAN,OIL |
oil pan (C:4V:2WD:MT; 1997-04-01~1998-11-01) |
| 11531-60C00-000 |
FILLER,OIL |
oil pan (C:4V:2WD:MT; 1997-04-01~1998-11-01) |
| 11541-60C00-000 |
HOSE,OIL FILLER |
oil pan (C:4V:2WD:MT; 1997-04-01~1998-11-01) |
| 16520-70D00-000 |
STRAINER,OIL PUMP |
oil pan (C:4V:2WD:MT; 1997-04-01~1998-11-01) |
| 16910-60C22-000 |
ゲージ,オイルレベル |
oil pan (C:4V:2WD:MT; 1997-04-01~1998-11-01) |
| 16910-60C2V-000 |
GAUGE,OIL LEVEL |
oil pan (C:4V:2WD:MT; 1997-04-01~1998-11-01) |
| 16921-60C00-000 |
Cap,oil filler |
oil pan (C:4V:2WD:MT; 1997-04-01~1998-11-01) |
