| 01147-06123-000 |
ボルト |
rear wheel brakes (V:2WD:(A1ノゾクグレード),V:4WD; V:2WD:(PC,GL,PL,PX,PY,PS,EX,RX),V:4WD; 1990-01-01~1991-08-01) |
| 01570-0612B-000 |
Bolt - Bolt, upper |
rear wheel brakes (V:2WD:(A1ノゾクグレード),V:4WD; V:2WD:(PC,GL,PL,PX,PY,PS,EX,RX),V:4WD; 1990-01-01~1991-08-01) |
| 09159-08075-000 |
NUT |
rear wheel brakes (V:2WD:(A1ノゾクグレード),V:4WD; V:2WD:(PC,GL,PL,PX,PY,PS,EX,RX),V:4WD; 1990-01-01~1991-08-01) |
| 52241-73040-000 |
PIN,SHOE HOLD DOWN |
rear wheel brakes (V:2WD:(A1ノゾクグレード),V:4WD; V:2WD:(PC,GL,PL,PX,PY,PS,EX,RX),V:4WD; 1990-01-01~1991-08-01) |
| 52241-85400-000 |
PIN |
rear wheel brakes (V:2WD:(A1ノゾクグレード),V:4WD; V:2WD:(PC,GL,PL,PX,PY,PS,EX,RX),V:4WD; 1990-01-01~1991-08-01) |
| 52243-70AA0-000 |
SPRING,SHOE CLAMP |
rear wheel brakes (V:2WD:(A1ノゾクグレード),V:4WD; V:2WD:(PC,GL,PL,PX,PY,PS,EX,RX),V:4WD; 1990-01-01~1991-08-01) |
| 52243-79241-000 |
SPRING |
rear wheel brakes (V:2WD:(A1ノゾクグレード),V:4WD; V:2WD:(PC,GL,PL,PX,PY,PS,EX,RX),V:4WD; 1990-01-01~1991-08-01) |
| 52473-83040-000 |
プラグ,ブリーダ |
rear wheel brakes (V:2WD:(A1ノゾクグレード),V:4WD; V:2WD:(PC,GL,PL,PX,PY,PS,EX,RX),V:4WD; 1990-01-01~1991-08-01) |
| 52474-85200-000 |
キャップ,ブリーダプラグ |
rear wheel brakes (V:2WD:(A1ノゾクグレード),V:4WD; V:2WD:(PC,GL,PL,PX,PY,PS,EX,RX),V:4WD; 1990-01-01~1991-08-01) |
| 53110-70D00-000 |
プレート,リヤブレーキバッキング,ライト |
rear wheel brakes (V:2WD:(A1ノゾクグレード),V:4WD; V:2WD:(PC,GL,PL,PX,PY,PS,EX,RX),V:4WD; 1990-01-01~1991-08-01) |
| 53160-70D00-000 |
プレート,リヤブレーキバッキング,レフト |
rear wheel brakes (V:2WD:(A1ノゾクグレード),V:4WD; V:2WD:(PC,GL,PL,PX,PY,PS,EX,RX),V:4WD; 1990-01-01~1991-08-01) |
| 53200-80870-000 |
SHOE SET,BRAKE |
rear wheel brakes (V:2WD:(A1ノゾクグレード),V:4WD; V:2WD:(PC,GL,PL,PX,PY,PS,EX,RX),V:4WD; 1990-01-01~1991-08-01) |
| 53210-85250-000 |
シュー,ブレーキ |
rear wheel brakes (V:2WD:(A1ノゾクグレード),V:4WD; V:2WD:(PC,GL,PL,PX,PY,PS,EX,RX),V:4WD; 1990-01-01~1991-08-01) |
| 53231-83041-000 |
SPRING,SHOE RETURN B |
rear wheel brakes (V:2WD:(A1ノゾクグレード),V:4WD; V:2WD:(PC,GL,PL,PX,PY,PS,EX,RX),V:4WD; 1990-01-01~1991-08-01) |
| 53331-85200-000 |
SPRING,SHOE RETURN UPPER,R |
rear wheel brakes (V:2WD:(A1ノゾクグレード),V:4WD; V:2WD:(PC,GL,PL,PX,PY,PS,EX,RX),V:4WD; 1990-01-01~1991-08-01) |
| 53332-85200-000 |
SPRING,SHOE RETURN LOWER,L |
rear wheel brakes (V:2WD:(A1ノゾクグレード),V:4WD; V:2WD:(PC,GL,PL,PX,PY,PS,EX,RX),V:4WD; 1990-01-01~1991-08-01) |
| 53400-85840-000 |
BOOT&CUP SET,RR WHEEL CYL |
rear wheel brakes (V:2WD:(A1ノゾクグレード),V:4WD; V:2WD:(PC,GL,PL,PX,PY,PS,EX,RX),V:4WD; 1990-01-01~1991-08-01) |
| 53401-85240-000 |
CYLINDER ASSY,REAR WHEEL,R |
rear wheel brakes (V:2WD:(A1ノゾクグレード),V:4WD; V:2WD:(PC,GL,PL,PX,PY,PS,EX,RX),V:4WD; 1990-01-01~1991-08-01) |
| 53402-85240-000 |
CYLINDER ASSY,REAR WHEEL,L |
rear wheel brakes (V:2WD:(A1ノゾクグレード),V:4WD; V:2WD:(PC,GL,PL,PX,PY,PS,EX,RX),V:4WD; 1990-01-01~1991-08-01) |
| 53441-80050-000 |
SPRING,WHEEL CYLINDER |
rear wheel brakes (V:2WD:(A1ノゾクグレード),V:4WD; V:2WD:(PC,GL,PL,PX,PY,PS,EX,RX),V:4WD; 1990-01-01~1991-08-01) |
| 53721-85201-000 |
LEVER,PARKING BRAKE SHOE,R |
rear wheel brakes (V:2WD:(A1ノゾクグレード),V:4WD; V:2WD:(PC,GL,PL,PX,PY,PS,EX,RX),V:4WD; 1990-01-01~1991-08-01) |
| 53726-85201-000 |
LEVER,PARKING BRAKE SHOE,L |
rear wheel brakes (V:2WD:(A1ノゾクグレード),V:4WD; V:2WD:(PC,GL,PL,PX,PY,PS,EX,RX),V:4WD; 1990-01-01~1991-08-01) |
| 53731-85200-000 |
PIN,PARKING BRAKE LEVER |
rear wheel brakes (V:2WD:(A1ノゾクグレード),V:4WD; V:2WD:(PC,GL,PL,PX,PY,PS,EX,RX),V:4WD; 1990-01-01~1991-08-01) |
| 53741-60A00-000 |
LEVER,STOPPER |
rear wheel brakes (V:2WD:(A1ノゾクグレード),V:4WD; V:2WD:(PC,GL,PL,PX,PY,PS,EX,RX),V:4WD; 1990-01-01~1991-08-01) |
| 53751-85200-000 |
CLIP,PARKING BRAKE LEVER |
rear wheel brakes (V:2WD:(A1ノゾクグレード),V:4WD; V:2WD:(PC,GL,PL,PX,PY,PS,EX,RX),V:4WD; 1990-01-01~1991-08-01) |
| 53810-85200-000 |
ROD,PARKING BRAKE,R |
rear wheel brakes (V:2WD:(A1ノゾクグレード),V:4WD; V:2WD:(PC,GL,PL,PX,PY,PS,EX,RX),V:4WD; 1990-01-01~1991-08-01) |
| 53816-85200-000 |
SPRING,ROD |
rear wheel brakes (V:2WD:(A1ノゾクグレード),V:4WD; V:2WD:(PC,GL,PL,PX,PY,PS,EX,RX),V:4WD; 1990-01-01~1991-08-01) |
| 53860-85200-000 |
ROD,PARKING BRAKE,L |
rear wheel brakes (V:2WD:(A1ノゾクグレード),V:4WD; V:2WD:(PC,GL,PL,PX,PY,PS,EX,RX),V:4WD; 1990-01-01~1991-08-01) |
| 55151-78451-000 |
PLUG,BLEEDER |
rear wheel brakes (V:2WD:(A1ノゾクグレード),V:4WD; V:2WD:(PC,GL,PL,PX,PY,PS,EX,RX),V:4WD; 1990-01-01~1991-08-01) |
| 55156-66310-000 |
CAP,BLEEDER PLUG - Cap, bleeder plug |
rear wheel brakes (V:2WD:(A1ノゾクグレード),V:4WD; V:2WD:(PC,GL,PL,PX,PY,PS,EX,RX),V:4WD; 1990-01-01~1991-08-01) |
| 59122-18410-000 |
Cap, bleeder plug |
rear wheel brakes (V:2WD:(A1ノゾクグレード),V:4WD; V:2WD:(PC,GL,PL,PX,PY,PS,EX,RX),V:4WD; 1990-01-01~1991-08-01) |
