Search › Model › BU223

BU223

Toyota DYNA-200-TOYOACE-G25 · 1999 · 3,304 parts · 180 categories

3,304 items

Front Spring & Shock Absorber ([05.1995 - ] (9505- )BU211,221 ; (9505- )BU213,223..30T ; (9505- )BU212..TD..IV3 ; (950 5- )BU222..ARL ,GEN,TAIW ; (9505- )BU212..DSL..ARL,GEN,TAIW) 24

#	OEM	Part name
48110	48110-3B610	Spring Assy, Front, Rh
48110	90389-16015	Bimetal Formed Bush(For Front Spring)
48110	90389-16030	BUSH
48111	48101-3B610	Leaf, Front Spring, No.1
48111	48101-3B620	Leaf, Front Spring, No.1
48112	48112-3B610	Leaf, Front Spring, No.2
48112	48112-3B620	Leaf, Front Spring, No.2
48113	48113-3B610	Leaf, Front Spring, No.3
48113	48113-3B620	Leaf, Front Spring, No.3
48114	48114-3B610	Leaf, Front Spring, No.4
48114	48114-3B620	Leaf, Front Spring, No.4
48115	48102-3B610	Leaf, Front Spring, No.5
48115	48102-3B620	Leaf, Front Spring, No.5
48116	48116-3B610	Leaf, Front Spring, No.6
48116	48116-3B620	Leaf, Front Spring, No.6
48117	48103-3B610	Leaf, Front Spring, No.7
48117	48103-3B620	Leaf, Front Spring, No.7
48118	48118-3B610	Leaf, Front Spring, No.8
48118	48118-3B620	Leaf, Front Spring, No.8
48119	48119-3B610	Leaf, Front Spring, No.9
48119	48119-3B620	Leaf, Front Spring, No.9
48120	48110-3B620	Spring Assy, Front, Rh
48147	48147-3B610	Bolt, Front Spring, Center
4828437130	48284-37130	Nut, Front Spring Center Bolt

OEM	Part name	Category
48101-3B610	Leaf, Front Spring, No.1	Front Spring & Shock Absorber ([05.1995 - ] (9505- )BU211,221 ; (9505- )BU213,223..30T ; (9505- )BU212..TD..IV3 ; (950 5- )BU222..ARL ,GEN,TAIW ; (9505- )BU212..DSL..ARL,GEN,TAIW)
48101-3B620	Leaf, Front Spring, No.1	Front Spring & Shock Absorber ([05.1995 - ] (9505- )BU211,221 ; (9505- )BU213,223..30T ; (9505- )BU212..TD..IV3 ; (950 5- )BU222..ARL ,GEN,TAIW ; (9505- )BU212..DSL..ARL,GEN,TAIW)
48102-3B610	Leaf, Front Spring, No.5	Front Spring & Shock Absorber ([05.1995 - ] (9505- )BU211,221 ; (9505- )BU213,223..30T ; (9505- )BU212..TD..IV3 ; (950 5- )BU222..ARL ,GEN,TAIW ; (9505- )BU212..DSL..ARL,GEN,TAIW)
48102-3B620	Leaf, Front Spring, No.5	Front Spring & Shock Absorber ([05.1995 - ] (9505- )BU211,221 ; (9505- )BU213,223..30T ; (9505- )BU212..TD..IV3 ; (950 5- )BU222..ARL ,GEN,TAIW ; (9505- )BU212..DSL..ARL,GEN,TAIW)
48103-3B610	Leaf, Front Spring, No.7	Front Spring & Shock Absorber ([05.1995 - ] (9505- )BU211,221 ; (9505- )BU213,223..30T ; (9505- )BU212..TD..IV3 ; (950 5- )BU222..ARL ,GEN,TAIW ; (9505- )BU212..DSL..ARL,GEN,TAIW)
48103-3B620	Leaf, Front Spring, No.7	Front Spring & Shock Absorber ([05.1995 - ] (9505- )BU211,221 ; (9505- )BU213,223..30T ; (9505- )BU212..TD..IV3 ; (950 5- )BU222..ARL ,GEN,TAIW ; (9505- )BU212..DSL..ARL,GEN,TAIW)
48110-3B610	Spring Assy, Front, Rh	Front Spring & Shock Absorber ([05.1995 - ] (9505- )BU211,221 ; (9505- )BU213,223..30T ; (9505- )BU212..TD..IV3 ; (950 5- )BU222..ARL ,GEN,TAIW ; (9505- )BU212..DSL..ARL,GEN,TAIW)
48110-3B620	Spring Assy, Front, Rh	Front Spring & Shock Absorber ([05.1995 - ] (9505- )BU211,221 ; (9505- )BU213,223..30T ; (9505- )BU212..TD..IV3 ; (950 5- )BU222..ARL ,GEN,TAIW ; (9505- )BU212..DSL..ARL,GEN,TAIW)
48112-3B610	Leaf, Front Spring, No.2	Front Spring & Shock Absorber ([05.1995 - ] (9505- )BU211,221 ; (9505- )BU213,223..30T ; (9505- )BU212..TD..IV3 ; (950 5- )BU222..ARL ,GEN,TAIW ; (9505- )BU212..DSL..ARL,GEN,TAIW)
48112-3B620	Leaf, Front Spring, No.2	Front Spring & Shock Absorber ([05.1995 - ] (9505- )BU211,221 ; (9505- )BU213,223..30T ; (9505- )BU212..TD..IV3 ; (950 5- )BU222..ARL ,GEN,TAIW ; (9505- )BU212..DSL..ARL,GEN,TAIW)
48113-3B610	Leaf, Front Spring, No.3	Front Spring & Shock Absorber ([05.1995 - ] (9505- )BU211,221 ; (9505- )BU213,223..30T ; (9505- )BU212..TD..IV3 ; (950 5- )BU222..ARL ,GEN,TAIW ; (9505- )BU212..DSL..ARL,GEN,TAIW)
48113-3B620	Leaf, Front Spring, No.3	Front Spring & Shock Absorber ([05.1995 - ] (9505- )BU211,221 ; (9505- )BU213,223..30T ; (9505- )BU212..TD..IV3 ; (950 5- )BU222..ARL ,GEN,TAIW ; (9505- )BU212..DSL..ARL,GEN,TAIW)
48114-3B610	Leaf, Front Spring, No.4	Front Spring & Shock Absorber ([05.1995 - ] (9505- )BU211,221 ; (9505- )BU213,223..30T ; (9505- )BU212..TD..IV3 ; (950 5- )BU222..ARL ,GEN,TAIW ; (9505- )BU212..DSL..ARL,GEN,TAIW)
48114-3B620	Leaf, Front Spring, No.4	Front Spring & Shock Absorber ([05.1995 - ] (9505- )BU211,221 ; (9505- )BU213,223..30T ; (9505- )BU212..TD..IV3 ; (950 5- )BU222..ARL ,GEN,TAIW ; (9505- )BU212..DSL..ARL,GEN,TAIW)
48116-3B610	Leaf, Front Spring, No.6	Front Spring & Shock Absorber ([05.1995 - ] (9505- )BU211,221 ; (9505- )BU213,223..30T ; (9505- )BU212..TD..IV3 ; (950 5- )BU222..ARL ,GEN,TAIW ; (9505- )BU212..DSL..ARL,GEN,TAIW)
48116-3B620	Leaf, Front Spring, No.6	Front Spring & Shock Absorber ([05.1995 - ] (9505- )BU211,221 ; (9505- )BU213,223..30T ; (9505- )BU212..TD..IV3 ; (950 5- )BU222..ARL ,GEN,TAIW ; (9505- )BU212..DSL..ARL,GEN,TAIW)
48118-3B610	Leaf, Front Spring, No.8	Front Spring & Shock Absorber ([05.1995 - ] (9505- )BU211,221 ; (9505- )BU213,223..30T ; (9505- )BU212..TD..IV3 ; (950 5- )BU222..ARL ,GEN,TAIW ; (9505- )BU212..DSL..ARL,GEN,TAIW)
48118-3B620	Leaf, Front Spring, No.8	Front Spring & Shock Absorber ([05.1995 - ] (9505- )BU211,221 ; (9505- )BU213,223..30T ; (9505- )BU212..TD..IV3 ; (950 5- )BU222..ARL ,GEN,TAIW ; (9505- )BU212..DSL..ARL,GEN,TAIW)
48119-3B610	Leaf, Front Spring, No.9	Front Spring & Shock Absorber ([05.1995 - ] (9505- )BU211,221 ; (9505- )BU213,223..30T ; (9505- )BU212..TD..IV3 ; (950 5- )BU222..ARL ,GEN,TAIW ; (9505- )BU212..DSL..ARL,GEN,TAIW)
48119-3B620	Leaf, Front Spring, No.9	Front Spring & Shock Absorber ([05.1995 - ] (9505- )BU211,221 ; (9505- )BU213,223..30T ; (9505- )BU212..TD..IV3 ; (950 5- )BU222..ARL ,GEN,TAIW ; (9505- )BU212..DSL..ARL,GEN,TAIW)
48147-3B610	Bolt, Front Spring, Center	Front Spring & Shock Absorber ([05.1995 - ] (9505- )BU211,221 ; (9505- )BU213,223..30T ; (9505- )BU212..TD..IV3 ; (950 5- )BU222..ARL ,GEN,TAIW ; (9505- )BU212..DSL..ARL,GEN,TAIW)
48284-37130	Nut, Front Spring Center Bolt	Front Spring & Shock Absorber ([05.1995 - ] (9505- )BU211,221 ; (9505- )BU213,223..30T ; (9505- )BU212..TD..IV3 ; (950 5- )BU222..ARL ,GEN,TAIW ; (9505- )BU212..DSL..ARL,GEN,TAIW)
90389-16015	Bimetal Formed Bush(For Front Spring)	Front Spring & Shock Absorber ([05.1995 - ] (9505- )BU211,221 ; (9505- )BU213,223..30T ; (9505- )BU212..TD..IV3 ; (950 5- )BU222..ARL ,GEN,TAIW ; (9505- )BU212..DSL..ARL,GEN,TAIW)
90389-16030	BUSH	Front Spring & Shock Absorber ([05.1995 - ] (9505- )BU211,221 ; (9505- )BU213,223..30T ; (9505- )BU212..TD..IV3 ; (950 5- )BU222..ARL ,GEN,TAIW ; (9505- )BU212..DSL..ARL,GEN,TAIW)
