BU182

Toyota DYNA-200-TOYOACE-G25 · 1995 · 4,049 parts · 210 categories

← Back to categories

4,049 items

Front Spring & Shock Absorber ([09.1996 - ] (9505-9609)BU162,172,182..DM7,T3 ; (9609- )BU 172..T3 ; (9609- )BU162,182..DM7 ,T3,T4..02S) 17

#	OEM	Part name
48110	48110-3B673	Spring Assy, Front, Rh
48110	90385-23005	Bush(For Front Spring Shackle)
48110	90385-23037	Bush(For Front Spring Shackle)
48110	48299-36010	Bimetal Formed Bush(For Front Spring)
48111	48101-3B673	Leaf, Front Spring, No.1
48111	48101-3B683	Leaf, Front Spring, No.1
48112	48112-3B673	Leaf, Front Spring, No.2
48112	48112-3B683	Leaf, Front Spring, No.2
48113	48102-3B673	Leaf, Front Spring, No.3
48113	48102-3B683	Leaf, Front Spring, No.3
48120	48110-3B683	Spring Assy, Front, Lh
48141	48141-35021	Clip, Front Spring, No.1
48147	48147-37280	Bolt, Front Spring, Center
48153	48254-3B521	Spacer, Front Leaf Spring, No.1
48253	48253-25670	Leaf, Front Spring, No.5
48253	48253-3B691	Spacer, Rear Spring, No.1
4828437130	48284-37130	Nut, Front Spring Center Bolt

OEM	Part name	Category
48101-3B673	Leaf, Front Spring, No.1	Front Spring & Shock Absorber ([09.1996 - ] (9505-9609)BU162,172,182..DM7,T3 ; (9609- )BU 172..T3 ; (9609- )BU162,182..DM7 ,T3,T4..02S)
48101-3B683	Leaf, Front Spring, No.1	Front Spring & Shock Absorber ([09.1996 - ] (9505-9609)BU162,172,182..DM7,T3 ; (9609- )BU 172..T3 ; (9609- )BU162,182..DM7 ,T3,T4..02S)
48102-3B673	Leaf, Front Spring, No.3	Front Spring & Shock Absorber ([09.1996 - ] (9505-9609)BU162,172,182..DM7,T3 ; (9609- )BU 172..T3 ; (9609- )BU162,182..DM7 ,T3,T4..02S)
48102-3B683	Leaf, Front Spring, No.3	Front Spring & Shock Absorber ([09.1996 - ] (9505-9609)BU162,172,182..DM7,T3 ; (9609- )BU 172..T3 ; (9609- )BU162,182..DM7 ,T3,T4..02S)
48110-3B673	Spring Assy, Front, Rh	Front Spring & Shock Absorber ([09.1996 - ] (9505-9609)BU162,172,182..DM7,T3 ; (9609- )BU 172..T3 ; (9609- )BU162,182..DM7 ,T3,T4..02S)
48110-3B683	Spring Assy, Front, Lh	Front Spring & Shock Absorber ([09.1996 - ] (9505-9609)BU162,172,182..DM7,T3 ; (9609- )BU 172..T3 ; (9609- )BU162,182..DM7 ,T3,T4..02S)
48112-3B673	Leaf, Front Spring, No.2	Front Spring & Shock Absorber ([09.1996 - ] (9505-9609)BU162,172,182..DM7,T3 ; (9609- )BU 172..T3 ; (9609- )BU162,182..DM7 ,T3,T4..02S)
48112-3B683	Leaf, Front Spring, No.2	Front Spring & Shock Absorber ([09.1996 - ] (9505-9609)BU162,172,182..DM7,T3 ; (9609- )BU 172..T3 ; (9609- )BU162,182..DM7 ,T3,T4..02S)
48141-35021	Clip, Front Spring, No.1	Front Spring & Shock Absorber ([09.1996 - ] (9505-9609)BU162,172,182..DM7,T3 ; (9609- )BU 172..T3 ; (9609- )BU162,182..DM7 ,T3,T4..02S)
48147-37280	Bolt, Front Spring, Center	Front Spring & Shock Absorber ([09.1996 - ] (9505-9609)BU162,172,182..DM7,T3 ; (9609- )BU 172..T3 ; (9609- )BU162,182..DM7 ,T3,T4..02S)
48253-25670	Leaf, Front Spring, No.5	Front Spring & Shock Absorber ([09.1996 - ] (9505-9609)BU162,172,182..DM7,T3 ; (9609- )BU 172..T3 ; (9609- )BU162,182..DM7 ,T3,T4..02S)
48253-3B691	Spacer, Rear Spring, No.1	Front Spring & Shock Absorber ([09.1996 - ] (9505-9609)BU162,172,182..DM7,T3 ; (9609- )BU 172..T3 ; (9609- )BU162,182..DM7 ,T3,T4..02S)
48254-3B521	Spacer, Front Leaf Spring, No.1	Front Spring & Shock Absorber ([09.1996 - ] (9505-9609)BU162,172,182..DM7,T3 ; (9609- )BU 172..T3 ; (9609- )BU162,182..DM7 ,T3,T4..02S)
48284-37130	Nut, Front Spring Center Bolt	Front Spring & Shock Absorber ([09.1996 - ] (9505-9609)BU162,172,182..DM7,T3 ; (9609- )BU 172..T3 ; (9609- )BU162,182..DM7 ,T3,T4..02S)
48299-36010	Bimetal Formed Bush(For Front Spring)	Front Spring & Shock Absorber ([09.1996 - ] (9505-9609)BU162,172,182..DM7,T3 ; (9609- )BU 172..T3 ; (9609- )BU162,182..DM7 ,T3,T4..02S)
90385-23005	Bush(For Front Spring Shackle)	Front Spring & Shock Absorber ([09.1996 - ] (9505-9609)BU162,172,182..DM7,T3 ; (9609- )BU 172..T3 ; (9609- )BU162,182..DM7 ,T3,T4..02S)
90385-23037	Bush(For Front Spring Shackle)	Front Spring & Shock Absorber ([09.1996 - ] (9505-9609)BU162,172,182..DM7,T3 ; (9609- )BU 172..T3 ; (9609- )BU162,182..DM7 ,T3,T4..02S)
