| 13050-0Y020 |
Gear Assy, Camshaft Timing |
Camshaft & Valve ([04.2017 - ] (1704- )3NRVE) |
| 13070-BZ010 |
Gear Assy, Camshaft Timing Exhaust |
Camshaft & Valve ([04.2017 - ] (1704- )3NRVE) |
| 13501-BZ040 |
Camshaft |
Camshaft & Valve ([04.2017 - ] (1704- )3NRVE) |
| 13502-BZ040 |
Camshaft, No.2 |
Camshaft & Valve ([04.2017 - ] (1704- )3NRVE) |
| 13506-0Y040 |
Chain Sub-Assy |
Camshaft & Valve ([04.2017 - ] (1704- )3NRVE) |
| 13540-0Y010 |
Tensioner Assy, Chain, No.1 |
Camshaft & Valve ([04.2017 - ] (1704- )3NRVE) |
| 13562-0Y020 |
Damper, Chain Vibration, No.2 |
Camshaft & Valve ([04.2017 - ] (1704- )3NRVE) |
| 13566-0Y010 |
Guide, Timing Chain |
Camshaft & Valve ([04.2017 - ] (1704- )3NRVE) |
| 13591-0Y010 |
Arm, Timing Chain Tension |
Camshaft & Valve ([04.2017 - ] (1704- )3NRVE) |
| 13711-0Y020 |
Valve, Intake |
Camshaft & Valve ([04.2017 - ] (1704- )3NRVE) |
| 13715-0Y020 |
Valve, Exhaust |
Camshaft & Valve ([04.2017 - ] (1704- )3NRVE) |
| 13716-0C020 |
Cap, Valve Stem |
Camshaft & Valve ([04.2017 - ] (1704- )3NRVE) |
| 13734-0C010 |
Seat, Valve Spring |
Camshaft & Valve ([04.2017 - ] (1704- )3NRVE) |
| 13741-0Y010 |
Retainer, Valve Spring |
Camshaft & Valve ([04.2017 - ] (1704- )3NRVE) |
| 13750-0C040 |
Adjuster Assy, Valve Lash |
Camshaft & Valve ([04.2017 - ] (1704- )3NRVE) |
| 13801-0C030 |
Arm Sub-Assy, Valve Rocker, No.1 |
Camshaft & Valve ([04.2017 - ] (1704- )3NRVE) |
| 90080-31084 |
Seal Or Ring, O(For Valve Stem Oil) |
Camshaft & Valve ([04.2017 - ] (1704- )3NRVE) |
| 90080-31085 |
Seal Or Ring, O(For Valve Stem Oil) |
Camshaft & Valve ([04.2017 - ] (1704- )3NRVE) |
| 90501-T0045 |
Spring, Compression(For Inner) |
Camshaft & Valve ([04.2017 - ] (1704- )3NRVE) |
| 90913-03028 |
Lock, Valve Spring Retainer |
Camshaft & Valve ([04.2017 - ] (1704- )3NRVE) |
| 90913-T2004 |
Seal, Intake Valve Stem Oil |
Camshaft & Valve ([04.2017 - ] (1704- )3NRVE) |
| 90913-T2005 |
Seal, Exhaust Valve Stem Oil |
Camshaft & Valve ([04.2017 - ] (1704- )3NRVE) |
