AT175

Toyota CARINA · 1988 · 4,897 parts · 196 categories

← Back to categories

4,897 items

Valve Body & Oil Strainer (Atm) ([08.1988 - ] A241H (8808- )AT175..4FC) 18

#	OEM	Part name
35171	35171-12020	Cover, Transaxle Housing
35172	35172-12020	Gasket, Transaxle Housing Cover
35172	35172-12021	Gasket, Transaxle Housing Cover
35173	35173-12010	Plate, Transaxle Housing Cover
35173	35173-12011	Plate, Transaxle Housing Cover
35195	35195-12020	Clamp, Transaxle Apply Tube, No.1
35196	35196-12020	Clamp, Transaxle Apply Tube, No.2
35197	35197-12020	Clamp, Transaxle Apply Tube, No.3
35198	35198-12010	Clamp, Transaxle Apply Tube, No.4
35429	35429-12030	Tube, Line Pressure
35844	35844-12030	Tube, Accumulator Back Pressure, No.1
35845	35845-12030	Tube, Direct Clutch Accumulator
35846	35846-12040	Tube, Brake Accumulator
35847	35847-12020	Tube, Transmission Lube Apply
35848	35848-12030	Tube, Forward Clutch Accumulator
35899	35899-12020	Tube, Governor Pressure
9014960067	90149-60067	Bolt (For Stator Shaft)
9161160620	91611-60620	Screw Or Bolt(For Valve Rocker Shaft Lock)

OEM	Part name	Category
35171-12020	Cover, Transaxle Housing	Valve Body & Oil Strainer (Atm) ([08.1988 - ] A241H (8808- )AT175..4FC)
35172-12020	Gasket, Transaxle Housing Cover	Valve Body & Oil Strainer (Atm) ([08.1988 - ] A241H (8808- )AT175..4FC)
35172-12021	Gasket, Transaxle Housing Cover	Valve Body & Oil Strainer (Atm) ([08.1988 - ] A241H (8808- )AT175..4FC)
35173-12010	Plate, Transaxle Housing Cover	Valve Body & Oil Strainer (Atm) ([08.1988 - ] A241H (8808- )AT175..4FC)
35173-12011	Plate, Transaxle Housing Cover	Valve Body & Oil Strainer (Atm) ([08.1988 - ] A241H (8808- )AT175..4FC)
35195-12020	Clamp, Transaxle Apply Tube, No.1	Valve Body & Oil Strainer (Atm) ([08.1988 - ] A241H (8808- )AT175..4FC)
35196-12020	Clamp, Transaxle Apply Tube, No.2	Valve Body & Oil Strainer (Atm) ([08.1988 - ] A241H (8808- )AT175..4FC)
35197-12020	Clamp, Transaxle Apply Tube, No.3	Valve Body & Oil Strainer (Atm) ([08.1988 - ] A241H (8808- )AT175..4FC)
35198-12010	Clamp, Transaxle Apply Tube, No.4	Valve Body & Oil Strainer (Atm) ([08.1988 - ] A241H (8808- )AT175..4FC)
35429-12030	Tube, Line Pressure	Valve Body & Oil Strainer (Atm) ([08.1988 - ] A241H (8808- )AT175..4FC)
35844-12030	Tube, Accumulator Back Pressure, No.1	Valve Body & Oil Strainer (Atm) ([08.1988 - ] A241H (8808- )AT175..4FC)
35845-12030	Tube, Direct Clutch Accumulator	Valve Body & Oil Strainer (Atm) ([08.1988 - ] A241H (8808- )AT175..4FC)
35846-12040	Tube, Brake Accumulator	Valve Body & Oil Strainer (Atm) ([08.1988 - ] A241H (8808- )AT175..4FC)
35847-12020	Tube, Transmission Lube Apply	Valve Body & Oil Strainer (Atm) ([08.1988 - ] A241H (8808- )AT175..4FC)
35848-12030	Tube, Forward Clutch Accumulator	Valve Body & Oil Strainer (Atm) ([08.1988 - ] A241H (8808- )AT175..4FC)
35899-12020	Tube, Governor Pressure	Valve Body & Oil Strainer (Atm) ([08.1988 - ] A241H (8808- )AT175..4FC)
90149-60067	Bolt (For Stator Shaft)	Valve Body & Oil Strainer (Atm) ([08.1988 - ] A241H (8808- )AT175..4FC)
91611-60620	Screw Or Bolt(For Valve Rocker Shaft Lock)	Valve Body & Oil Strainer (Atm) ([08.1988 - ] A241H (8808- )AT175..4FC)
