| 13010-PCX-A04 |
Piston set a - STD. |
Piston/crankshaft |
| 13011-PCX-024 |
Ring set - PISTON (STD.) (RIKEN) |
Piston/crankshaft |
| 13020-PCX-A04 |
Piston set b - STD. |
Piston/crankshaft |
| 13021-PCX-024 |
Ring set - PISTON (OS 0.25) (RIKEN) |
Piston/crankshaft |
| 13030-PCX-A03 |
Piston set - OS 0.25 |
Piston/crankshaft |
| 13050-PCX-A00 |
Rod set - CONNECTING |
Piston/crankshaft |
| 13060-PCX-000 |
Piston pin set |
Piston/crankshaft |
| 13115-PCX-000 |
Clip - PISTON PIN, 1.6MM |
Piston/crankshaft |
| 13204-PCX-003 |
Bolt - CONNECTING ROD |
Piston/crankshaft |
| 13211-PCX-013 |
BEARING A - CONNECTING ROD (BLUE) (DAIDO) |
Piston/crankshaft |
| 13212-PCX-013 |
Bearing b - CONNECTING ROD (BLACK) (DAIDO) |
Piston/crankshaft |
| 13213-PCX-013 |
Bearing c - CONNECTING ROD (BROWN) (DAIDO) |
Piston/crankshaft |
| 13214-PCX-013 |
Bearing d - CONNECTING ROD (GREEN) (DAIDO) |
Piston/crankshaft |
| 13215-PCX-013 |
Bearing e - CONNECTING ROD (YELLOW) (DAIDO) |
Piston/crankshaft |
| 13216-PCX-013 |
Bearing f - CONNECTING ROD (PINK) (DAIDO) |
Piston/crankshaft |
| 13217-PCX-013 |
Bearing g - CONNECTING ROD (RED) (DAIDO) |
Piston/crankshaft |
| 13310-PCX-010 |
Crankshaft comp. |
Piston/crankshaft |
| 13321-PCX-013 |
BEARING A - MAIN (BLUE) (DAIDO) |
Piston/crankshaft |
| 13322-PCX-013 |
Bearing b - MAIN (BLACK) (DAIDO) |
Piston/crankshaft |
| 13323-PCX-013 |
Bearing c - MAIN (BROWN) (DAIDO) |
Piston/crankshaft |
| 13324-PCX-013 |
Bearing d - MAIN (GREEN) (DAIDO) |
Piston/crankshaft |
| 13325-PCX-013 |
Bearing e - MAIN (YELLOW) (DAIDO) |
Piston/crankshaft |
| 13326-PCX-013 |
Bearing f - MAIN (PINK) (DAIDO) |
Piston/crankshaft |
| 13331-PCX-003 |
Washer - THRUST (DAIDO) |
Piston/crankshaft |
| 13620-PCX-004 |
Sprocket - DRIVE CHAIN |
Piston/crankshaft |
| 13622-PCX-013 |
Plate - CRANK PULSER |
Piston/crankshaft |
| 13810-PCX-003 |
Pulley comp - CRANKSHAFT |
Piston/crankshaft |
| 90017-PCX-013 |
Bolt-washer - 16X49 |
Piston/crankshaft |
| 90704-PT0-000 |
Key - 4.5X38.5 |
Piston/crankshaft |
