AP1
Front windshield 8
| # | OEM | Part name |
|---|---|---|
| 1 | 04731-S2A-000 | Rubber set - FR. WINDSHIELD DAM |
| 2 | 73111-S2A-G01 | Glass set - FR. WINDSHIELD (GREEN) (AGC) |
| 3 | 73122-S04-000 | Seal a - FR. WINDSHIELD MOLDING |
| 4 | 73127-S2A-003 | Seal - FR. WINDSHIELD MOLDING SIDE |
| 5 | 73150-S2A-013 | Molding - FR. WINDSHIELD |
| 6 | 78527-S04-E80 | Label - SRS CAUTION (CHILD SEAT) |
| 7 | 91568-SX0-003 | Fastener a - WINDSHIELD |
| 8 | 91569-SX0-013 | Fastener b - WINDSHIELD |
| OEM | Part name | Category |
|---|---|---|
| 04731-S2A-000 | Rubber set - FR. WINDSHIELD DAM | Front windshield |
| 73111-S2A-G01 | Glass set - FR. WINDSHIELD (GREEN) (AGC) | Front windshield |
| 73122-S04-000 | Seal a - FR. WINDSHIELD MOLDING | Front windshield |
| 73127-S2A-003 | Seal - FR. WINDSHIELD MOLDING SIDE | Front windshield |
| 73150-S2A-013 | Molding - FR. WINDSHIELD | Front windshield |
| 78527-S04-E80 | Label - SRS CAUTION (CHILD SEAT) | Front windshield |
| 91568-SX0-003 | Fastener a - WINDSHIELD | Front windshield |
| 91569-SX0-013 | Fastener b - WINDSHIELD | Front windshield |
