Search › Model › AL11

AL11

Toyota TERCEL · 1979 · 4,645 parts · 173 categories

4,645 items

Steering Column & Shaft ([01.1979 - ] (7901- )RHD) 44

#	OEM	Part name
45222	45222-16010	Cover, Steering Gear Dust
45501	45501-16010	Housing Sub-Assy, Steering Rack
45501	45501-16170	Housing Sub-Assy, Steering Rack
45501	90311-15001	Seal, Oil(For Steering Bevel Gear Housing)
45501	90311-15002	Seal, Oil(For Steering Bevel Gear Housing)
45501	90363-13001	Bearing, Radial Ball(For Steering Rack Housing)
45501	90363-15002	Bearing, Radial Ball(For Steering Rack Housing) - RADIAL BALL(FOR STEERING PINION LOWER)
45501	90363-15003	Bearing, Radial Ball(For Steering Rack Housing)
45501	90560-15003	Spacer(For Steering Rack Housing)
45503	45503-19015	End Sub-Assy, Steering Rack(For Power Steering)
45510	45510-16010	Gear Assy, Steering
45510	45510-16011	Gear Assy, Steering
45514	45514-16010	Bracket, Steering Rack Housing, No.1
45515	45515-16010	Bracket, Steering Rack Housing, No.2
45516	45516-10010	Grommet, Steering Rack Housing, No.1
45517	45517-16010	Grommet, Steering Rack Housing, No.2
45521	45521-16010	Rack, Steering
45521	45521-16011	Rack, Steering
45522	45522-10010	Bush, Steering Rack
45522	45522-10021	Bush, Steering Rack
45522	45522-10030	Bush, Steering Rack
45523	45523-10010	Guide, Rack(For Steering Gear)
45523	45523-16011	Guide, Rack(For Steering Gear)
45523	90501-23007	Spring(For Power Steering Rack Guide)
45523	90560-23003	Spacer(For Rack Guide)
45524	45524-10010	Cap, Steering Rack Guide Spring
45524	45524-16010	Cap(For Power Steering Pinion)
45524	90179-36001	Nut(For Steering Rack Guide Spring Cap)
45535	45535-10020	Boot, Steering Rack, No.1
45535	45535-10021	Boot, Steering Rack, No.1
45535	90461-10273	Clamp(For Steering Rack Boot)
45535	90467-18003	Clip Or Clamp(For Ventilation Hose)
45535	90467-28002	Clip(For Steering Rack Boot)
45536	45536-10020	Boot, Steering Rack, No.2
45536	45536-10021	Boot, Steering Rack, No.2
45537	90214-14002	Washer, Claw(For Power Steering Rack End)
45539	45539-10010	Guide, Rear Steering Control Cable, No.1
45541	45541-16010	Pinion, Steering
45541	45541-16900	Pinion, Steering
45545	45545-10010	Screw, Pinion Bearing Adjusting
45545	90179-38001	Nut(For Pinion Bearing Adjusting Screw)
9011910084	90119-10084	New Genuine Part
9011910106	90119-10106	New Genuine Part
9326963020	93269-63020	Screw(For Steering Rack Boot Clamp)

OEM	Part name	Category
45222-16010	Cover, Steering Gear Dust	Steering Column & Shaft ([01.1979 - ] (7901- )RHD)
45501-16010	Housing Sub-Assy, Steering Rack	Steering Column & Shaft ([01.1979 - ] (7901- )RHD)
45501-16170	Housing Sub-Assy, Steering Rack	Steering Column & Shaft ([01.1979 - ] (7901- )RHD)
45503-19015	End Sub-Assy, Steering Rack(For Power Steering)	Steering Column & Shaft ([01.1979 - ] (7901- )RHD)
45510-16010	Gear Assy, Steering	Steering Column & Shaft ([01.1979 - ] (7901- )RHD)
45510-16011	Gear Assy, Steering	Steering Column & Shaft ([01.1979 - ] (7901- )RHD)
45514-16010	Bracket, Steering Rack Housing, No.1	Steering Column & Shaft ([01.1979 - ] (7901- )RHD)
45515-16010	Bracket, Steering Rack Housing, No.2	Steering Column & Shaft ([01.1979 - ] (7901- )RHD)
45516-10010	Grommet, Steering Rack Housing, No.1	Steering Column & Shaft ([01.1979 - ] (7901- )RHD)
45517-16010	Grommet, Steering Rack Housing, No.2	Steering Column & Shaft ([01.1979 - ] (7901- )RHD)
45521-16010	Rack, Steering	Steering Column & Shaft ([01.1979 - ] (7901- )RHD)
45521-16011	Rack, Steering	Steering Column & Shaft ([01.1979 - ] (7901- )RHD)
45522-10010	Bush, Steering Rack	Steering Column & Shaft ([01.1979 - ] (7901- )RHD)
45522-10021	Bush, Steering Rack	Steering Column & Shaft ([01.1979 - ] (7901- )RHD)
45522-10030	Bush, Steering Rack	Steering Column & Shaft ([01.1979 - ] (7901- )RHD)
45523-10010	Guide, Rack(For Steering Gear)	Steering Column & Shaft ([01.1979 - ] (7901- )RHD)
45523-16011	Guide, Rack(For Steering Gear)	Steering Column & Shaft ([01.1979 - ] (7901- )RHD)
45524-10010	Cap, Steering Rack Guide Spring	Steering Column & Shaft ([01.1979 - ] (7901- )RHD)
45524-16010	Cap(For Power Steering Pinion)	Steering Column & Shaft ([01.1979 - ] (7901- )RHD)
45535-10020	Boot, Steering Rack, No.1	Steering Column & Shaft ([01.1979 - ] (7901- )RHD)
45535-10021	Boot, Steering Rack, No.1	Steering Column & Shaft ([01.1979 - ] (7901- )RHD)
45536-10020	Boot, Steering Rack, No.2	Steering Column & Shaft ([01.1979 - ] (7901- )RHD)
45536-10021	Boot, Steering Rack, No.2	Steering Column & Shaft ([01.1979 - ] (7901- )RHD)
45539-10010	Guide, Rear Steering Control Cable, No.1	Steering Column & Shaft ([01.1979 - ] (7901- )RHD)
45541-16010	Pinion, Steering	Steering Column & Shaft ([01.1979 - ] (7901- )RHD)
45541-16900	Pinion, Steering	Steering Column & Shaft ([01.1979 - ] (7901- )RHD)
45545-10010	Screw, Pinion Bearing Adjusting	Steering Column & Shaft ([01.1979 - ] (7901- )RHD)
90119-10084	New Genuine Part	Steering Column & Shaft ([01.1979 - ] (7901- )RHD)
90119-10106	New Genuine Part	Steering Column & Shaft ([01.1979 - ] (7901- )RHD)
90179-36001	Nut(For Steering Rack Guide Spring Cap)	Steering Column & Shaft ([01.1979 - ] (7901- )RHD)
90179-38001	Nut(For Pinion Bearing Adjusting Screw)	Steering Column & Shaft ([01.1979 - ] (7901- )RHD)
90214-14002	Washer, Claw(For Power Steering Rack End)	Steering Column & Shaft ([01.1979 - ] (7901- )RHD)
90311-15001	Seal, Oil(For Steering Bevel Gear Housing)	Steering Column & Shaft ([01.1979 - ] (7901- )RHD)
90311-15002	Seal, Oil(For Steering Bevel Gear Housing)	Steering Column & Shaft ([01.1979 - ] (7901- )RHD)
90363-13001	Bearing, Radial Ball(For Steering Rack Housing)	Steering Column & Shaft ([01.1979 - ] (7901- )RHD)
90363-15002	Bearing, Radial Ball(For Steering Rack Housing) - RADIAL BALL(FOR STEERING PINION LOWER)	Steering Column & Shaft ([01.1979 - ] (7901- )RHD)
90363-15003	Bearing, Radial Ball(For Steering Rack Housing)	Steering Column & Shaft ([01.1979 - ] (7901- )RHD)
90461-10273	Clamp(For Steering Rack Boot)	Steering Column & Shaft ([01.1979 - ] (7901- )RHD)
90467-18003	Clip Or Clamp(For Ventilation Hose)	Steering Column & Shaft ([01.1979 - ] (7901- )RHD)
90467-28002	Clip(For Steering Rack Boot)	Steering Column & Shaft ([01.1979 - ] (7901- )RHD)
90501-23007	Spring(For Power Steering Rack Guide)	Steering Column & Shaft ([01.1979 - ] (7901- )RHD)
90560-15003	Spacer(For Steering Rack Housing)	Steering Column & Shaft ([01.1979 - ] (7901- )RHD)
90560-23003	Spacer(For Rack Guide)	Steering Column & Shaft ([01.1979 - ] (7901- )RHD)
93269-63020	Screw(For Steering Rack Boot Clamp)	Steering Column & Shaft ([01.1979 - ] (7901- )RHD)
