| 28011-16040 |
Clutch Sub-Assy, Starter |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 28011-26042 |
Clutch Sub-Assy, Starter |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 28013-70020 |
Bearing, Starter Center & Shock Absorber, No.1 |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 28013-70030 |
Bearing, Starter Center & Shock Absorber, No.1 |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 28014-70020 |
Shaft Sub-Assy, Planet Carrier |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 28100-16020 |
Starter Assy |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 28100-16040 |
Starter Assy |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 28100-16041 |
Starter Assy |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 28100-16071 |
Starter Assy |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 28100-16110 |
Starter Assy |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 28100-16130 |
Starter Assy |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 28110-16020 |
Housing Assy, Starter Drive |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 28110-16040 |
Housing Assy, Starter Drive |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 28110-16041 |
Housing Assy, Starter Drive |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 28113-16070 |
Lever, Starter Pinion Drive |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 28120-26071 |
Yoke Assy, Starter |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 28120-70020 |
Yoke Assy, Starter |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 28130-16070 |
Frame Assy, Starter Commutator End |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 28130-72010 |
Frame Assy, Starter Commutator End |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 28140-26070 |
Holder Assy, Starter Brush |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 28140-70020 |
Holder Assy, Starter Brush |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 28142-70020 |
Brush, Starter |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 28143-70020 |
Spring, Starter Brush |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 28150-10020 |
Switch Assy, Magnet Starter |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 28150-10021 |
Switch Assy, Magnet Starter |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 28150-16110 |
Switch Assy, Magnet Starter |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 28150-72080 |
Switch Assy, Magnet Starter |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 28160-26070 |
Armature Assy, Starter |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 28160-26071 |
Armature Assy, Starter |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 28160-70021 |
Armature Assy, Starter |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 28163-70020 |
Nut Or Collar, Pinion Stop, Starter |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 28176-15090 |
Screw, Starter |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 28176-87701 |
Screw, Starter |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 28177-70020 |
Plate(For Starter Armature) |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 28199-46080 |
Cover, Starter End Frame |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 28199-70020 |
Cover, Starter End Frame |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 28255-70020 |
Gear, Planet |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 28256-70020 |
Gear, Starter Internal |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 90096-90030 |
Ring, Snap, Starter Clutch Housing Disc |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 90099-01538 |
New Genuine Part |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 90099-01539 |
New Genuine Part |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 90099-01542 |
New Genuine Part |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 90099-04373 |
BOLTTHROUGH |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 90099-05178 |
New Genuine Part |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 90099-07124 |
Bearing(For Starter Housing) |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 90099-10180 |
Bush Or Bearing, Planet Carrier Shaft |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 90099-10181 |
Bearing, Starter Center & Shock Absorber, No.2 |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 90099-10182 |
Bearing(For Starter Housing) |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 90099-10183 |
Bearing, Starter Flange |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 90099-12405 |
New Genuine Part |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 90099-14092 |
Ring, O(For Starter Yoke) |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 90099-17112 |
Spring, Starter Brush |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 90119-10466 |
Bolt(For Transaxle & Engine Setting) |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 90179-08146 |
Nut |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 90179-08204 |
Nut |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 91612-61050 |
Bolt(For Transaxle & Engine Setting) |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 94110-40800 |
Nut(For Steering Damper) |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 94130-00802 |
Nut, No.1 (For Center Support Bearing) |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
| 95411-00800 |
New Genuine Part |
Starter ([02.1988 - ] 12V 0.8KW (8710- )4AF# ; (8711- )5AF#..MTM ; (8802- )5AF#..ATM) |
