| 01421-06453-000 |
スタッドボルト |
timing belt (DOHC; 1988-08-01~) |
| 01421-0645A-000 |
BOLT,STUD |
timing belt (DOHC; 1988-08-01~) |
| 01550-06163-000 |
Bolt |
timing belt (DOHC; 1988-08-01~) |
| 01550-0616A-000 |
Bolt |
timing belt (DOHC; 1988-08-01~) |
| 01550-0616B-000 |
Bolt |
timing belt (DOHC; 1988-08-01~) |
| 01550-06253-000 |
Bolt (6x25) |
timing belt (DOHC; 1988-08-01~) |
| 01550-0625A-000 |
Bolt |
timing belt (DOHC; 1988-08-01~) |
| 01550-0625B-000 |
Bolt - Bolt, head cover |
timing belt (DOHC; 1988-08-01~) |
| 01550-06403-000 |
Bolt (green) - Bolt, engine controlunit |
timing belt (DOHC; 1988-08-01~) |
| 01550-0640A-000 |
Bolt - Bolt (l:40) |
timing belt (DOHC; 1988-08-01~) |
| 01550-0640B-000 |
Bolt |
timing belt (DOHC; 1988-08-01~) |
| 01550-08353-000 |
Bolt, rear |
timing belt (DOHC; 1988-08-01~) |
| 01550-0835A-000 |
Bolt |
timing belt (DOHC; 1988-08-01~) |
| 01550-0835B-000 |
Bolt |
timing belt (DOHC; 1988-08-01~) |
| 01550-12253-000 |
Bolt |
timing belt (DOHC; 1988-08-01~) |
| 01550-1225A-000 |
Bolt |
timing belt (DOHC; 1988-08-01~) |
| 04221-05109-000 |
PIN |
timing belt (DOHC; 1988-08-01~) |
| 08316-10063-000 |
Nut |
timing belt (DOHC; 1988-08-01~) |
| 08316-1006B-000 |
NUT |
timing belt (DOHC; 1988-08-01~) |
| 09103-06083-000 |
Bolt (6x12) |
timing belt (DOHC; 1988-08-01~) |
| 09103-06285-000 |
BOLT(6X12) - Bolt (6x12) |
timing belt (DOHC; 1988-08-01~) |
| 09108-06056-000 |
BOLT,STUD |
timing belt (DOHC; 1988-08-01~) |
| 09160-06109-000 |
WASHER(6.5X18X1.6) |
timing belt (DOHC; 1988-08-01~) |
| 11360-86501-000 |
COV,TIMING IN,NO.2 |
timing belt (DOHC; 1988-08-01~) |
| 11370-86501-000 |
COV,TIMING IN,NO.1 |
timing belt (DOHC; 1988-08-01~) |
| 11380-64B00-000 |
COVER,TIMING BELT OUT,1 |
timing belt (DOHC; 1988-08-01~) |
| 11390-53B01-000 |
COVER,TIMING OUTSIDE,NO.2 |
timing belt (DOHC; 1988-08-01~) |
| 11394-70B00-000 |
SEAL |
timing belt (DOHC; 1988-08-01~) |
| 11396-71C00-000 |
SEAL,TIMING BELT COVER OUT |
timing belt (DOHC; 1988-08-01~) |
| 11399-86501-000 |
Spacer |
timing belt (DOHC; 1988-08-01~) |
| 11407-53B01-000 |
BELT SET,TIMING |
timing belt (DOHC; 1988-08-01~) |
| 11482-86500-000 |
Seal,inside cover |
timing belt (DOHC; 1988-08-01~) |
| 11484-86501-000 |
SEAL,OUTSIDE COVER NO.1 |
timing belt (DOHC; 1988-08-01~) |
| 11499-60D00-000 |
ラベル,タイミングベルト |
timing belt (DOHC; 1988-08-01~) |
| 12741-53B01-000 |
PULLEY,CAMSHAFT TIMING |
timing belt (DOHC; 1988-08-01~) |
| 12810-53B01-000 |
TENSIONER ASSY,TIMING BELT |
timing belt (DOHC; 1988-08-01~) |
| 12821-82002-000 |
SPRING,TENSIONER |
timing belt (DOHC; 1988-08-01~) |
| 12822-82002-000 |
PLATE,TENSIONER |
timing belt (DOHC; 1988-08-01~) |
| 12823-82001-000 |
DAMPER,TENSIONER SPRING |
timing belt (DOHC; 1988-08-01~) |
