| 01421-08253-000 |
Stud bolt, no.2 |
Cylinder head (DOHC; 1988-08-01~) |
| 01421-0825A-000 |
BOLT,STUD |
Cylinder head (DOHC; 1988-08-01~) |
| 01547-06303-000 |
Bolt |
Cylinder head (DOHC; 1988-08-01~) |
| 01547-0630B-000 |
Bolt |
Cylinder head (DOHC; 1988-08-01~) |
| 01550-08253-000 |
Bolt, rear |
Cylinder head (DOHC; 1988-08-01~) |
| 01550-0825A-000 |
Bolt |
Cylinder head (DOHC; 1988-08-01~) |
| 01550-0825B-000 |
Bolt |
Cylinder head (DOHC; 1988-08-01~) |
| 02112-06083-000 |
Screw |
Cylinder head (DOHC; 1988-08-01~) |
| 02112-0608A-000 |
SCREW |
Cylinder head (DOHC; 1988-08-01~) |
| 04211-13189-000 |
PIN |
Cylinder head (DOHC; 1988-08-01~) |
| 08316-10083-000 |
Nut |
Cylinder head (DOHC; 1988-08-01~) |
| 08316-1008B-000 |
NUT |
Cylinder head (DOHC; 1988-08-01~) |
| 09103-06132-000 |
BOLT(6X41) |
Cylinder head (DOHC; 1988-08-01~) |
| 09103-06185-000 |
BOLT(6X20) - Bolt (6x20) |
Cylinder head (DOHC; 1988-08-01~) |
| 09168-12016-000 |
GASKET(12.2X21X0.8) |
Cylinder head (DOHC; 1988-08-01~) |
| 09206-08001-000 |
PIN(8X11) |
Cylinder head (DOHC; 1988-08-01~) |
| 09241-22003-000 |
PLUG |
Cylinder head (DOHC; 1988-08-01~) |
| 09241-30009-000 |
Plug - Plug (od:30) |
Cylinder head (DOHC; 1988-08-01~) |
| 09241-30010-000 |
PLUG |
Cylinder head (DOHC; 1988-08-01~) |
| 09241-35002-000 |
PLUG |
Cylinder head (DOHC; 1988-08-01~) |
| 09246-05006-000 |
PLUG(1/8PT,H:5.5) |
Cylinder head (DOHC; 1988-08-01~) |
| 09251-09003-000 |
PLUG |
Cylinder head (DOHC; 1988-08-01~) |
| 09401-13413-000 |
Clip - Clip, air hose no.1 |
Cylinder head (DOHC; 1988-08-01~) |
| 09401-13417-000 |
CLIP |
Cylinder head (DOHC; 1988-08-01~) |
| 09482-00385-000 |
スパークプラグ,BP7ES |
Cylinder head (DOHC; 1988-08-01~) |
| 09482-00434-000 |
スパークプラグ,W22EPーU |
Cylinder head (DOHC; 1988-08-01~) |
| 09482-00495-000 |
スパークプラグ,BPR7ES |
Cylinder head (DOHC; 1988-08-01~) |
| 09482-00498-000 |
スパークプラグ,W22EPRーU |
Cylinder head (DOHC; 1988-08-01~) |
| 11100-64B01-000 |
Head assy,cylinder |
Cylinder head (DOHC; 1988-08-01~) |
| 11115-62D00-001 |
GUIDE,VALVE |
Cylinder head (DOHC; 1988-08-01~) |
| 11117-73G00-000 |
BOLT,CYLINDER HEAD |
Cylinder head (DOHC; 1988-08-01~) |
| 11118-86501-000 |
WASHER,CYLINDER HEAD BOLT |
Cylinder head (DOHC; 1988-08-01~) |
| 11139-86500-000 |
SEAL,CYLINDER HEAD SIDE |
Cylinder head (DOHC; 1988-08-01~) |
| 11141-86502-000 |
GASKET,CYL HEAD - Gasket, cylinder head |
Cylinder head (DOHC; 1988-08-01~) |
| 11170-64B01-000 |
カバー,シリンダヘッド |
Cylinder head (DOHC; 1988-08-01~) |
| 11170-64B10-000 |
カバー,シリンダヘッド |
Cylinder head (DOHC; 1988-08-01~) |
| 11170-64B20-000 |
カバー,シリンダヘッド |
Cylinder head (DOHC; 1988-08-01~) |
| 11170-64B90-000 |
Cover,cylinder head |
Cylinder head (DOHC; 1988-08-01~) |
| 11172-86501-000 |
PLATE,BREATHER |
Cylinder head (DOHC; 1988-08-01~) |
| 11189-86500-000 |
GASKET,CYL HEAD COVER |
Cylinder head (DOHC; 1988-08-01~) |
| 13650-64B00-000 |
Sensor,water Temp |
Cylinder head (DOHC; 1988-08-01~) |
| 16920-83G00-000 |
Cap,oil filler |
Cylinder head (DOHC; 1988-08-01~) |
| 16920-83G01-000 |
CAP OIL FILLER |
Cylinder head (DOHC; 1988-08-01~) |
| 16920-86502-000 |
Cap, oil filler |
Cylinder head (DOHC; 1988-08-01~) |
| 17690-64B02-000 |
Case comp,thermostat |
Cylinder head (DOHC; 1988-08-01~) |
| 17690-64X00-000 |
CASE,THERMOSTAT |
Cylinder head (DOHC; 1988-08-01~) |
| 17690-64X01-000 |
ケース,サーモスタット |
Cylinder head (DOHC; 1988-08-01~) |
| 17690-66B00-000 |
Case,thermostat |
Cylinder head (DOHC; 1988-08-01~) |
| 17699-64B00-000 |
GASKET,THERMOSTAT CASE |
Cylinder head (DOHC; 1988-08-01~) |
| 34850-14F00-000 |
GAUGE ASSY,WATER TEMP |
Cylinder head (DOHC; 1988-08-01~) |
| 34850-50A00-000 |
GAUGE ASSY,WATER TEMP - Gauge assy, water temperature |
Cylinder head (DOHC; 1988-08-01~) |
| 34850-82012-000 |
Gauge assy, water temperature |
Cylinder head (DOHC; 1988-08-01~) |
