A6I425
Radiator shroud (VQ40DE) 11
| # | OEM | Part name |
|---|---|---|
| 1 | 86721-82ZJ0-000 | Clip |
| 1 | 86721-82ZJ1-000 | Clip |
| 2 | 13781-82Z00-000 | Duct, air intake rh |
| 3 | 13782-82Z00-000 | Duct, air intake lh |
| 4 | 17760-82Z10-000 | Shroud, upper |
| 5 | 17770-82Z10-000 | Shroud, lower |
| 6 | 17100-82Z10-000 | Fan assy, condenser |
| 6 | 17100-82Z20-000 | Fan assy, condenser |
| 7 | 17765-50Z00-000 | スクリュ,シュラウド |
| 8 | 11958-82Z00-000 | Label, motor/fan caution |
| 9 | 17761-82Z00-000 | Nut |
| OEM | Part name | Category |
|---|---|---|
| 11958-82Z00-000 | Label, motor/fan caution | Radiator shroud (VQ40DE) |
| 13781-82Z00-000 | Duct, air intake rh | Radiator shroud (VQ40DE) |
| 13782-82Z00-000 | Duct, air intake lh | Radiator shroud (VQ40DE) |
| 17100-82Z10-000 | Fan assy, condenser | Radiator shroud (VQ40DE) |
| 17100-82Z20-000 | Fan assy, condenser | Radiator shroud (VQ40DE) |
| 17760-82Z10-000 | Shroud, upper | Radiator shroud (VQ40DE) |
| 17761-82Z00-000 | Nut | Radiator shroud (VQ40DE) |
| 17765-50Z00-000 | スクリュ,シュラウド | Radiator shroud (VQ40DE) |
| 17770-82Z10-000 | Shroud, lower | Radiator shroud (VQ40DE) |
| 86721-82ZJ0-000 | Clip | Radiator shroud (VQ40DE) |
| 86721-82ZJ1-000 | Clip | Radiator shroud (VQ40DE) |
