| 01551-0816C-000 |
Bolt |
Pedal/pedal bracket (A5B413D:RHD) |
| 08316-1006A-000 |
NUT |
Pedal/pedal bracket (A5B413D:RHD) |
| 08316-1010A-000 |
NUT - Nut, kick starter |
Pedal/pedal bracket (A5B413D:RHD) |
| 09100-10226-000 |
BOLT(10X85) |
Pedal/pedal bracket (A5B413D:RHD) |
| 09159-08127-000 |
NUT |
Pedal/pedal bracket (A5B413D:RHD) |
| 09180-10121-000 |
SPACER(10.1X13X73.8) |
Pedal/pedal bracket (A5B413D:RHD) |
| 09307-13005-000 |
BUSH - Bushing |
Pedal/pedal bracket (A5B413D:RHD) |
| 09321-06026-000 |
CUSHION |
Pedal/pedal bracket (A5B413D:RHD) |
| 49400-51K00-000 |
PEDAL ASSY,ACCELERATOR |
Pedal/pedal bracket (A5B413D:RHD) |
| 49511-72K00-000 |
BRACKET,ACCELERATOR PEDAL |
Pedal/pedal bracket (A5B413D:RHD) |
| 49600-51K00-000 |
PEDAL ASSY,BRAKE |
Pedal/pedal bracket (A5B413D:RHD) |
| 49720-72K20-000 |
Bracket, clutch pedal |
Pedal/pedal bracket (A5B413D:RHD) |
| 49751-58J00-000 |
PAD,PEDAL |
Pedal/pedal bracket (A5B413D:RHD) |
| 49751-58J20-000 |
PAD,PEDAL |
Pedal/pedal bracket (A5B413D:RHD) |
| 49810-72K20-000 |
Pedal, clutch |
Pedal/pedal bracket (A5B413D:RHD) |
| 49891-63J00-000 |
SPRING,CLUTCH PEDAL |
Pedal/pedal bracket (A5B413D:RHD) |
